Siemens SED2-LONI/F Installation Instructions

SED2 VFD LON Interface Option
Product Description
The L M ® certified SED2 VFD LON Interface
ON ARK
Option (LON Interface) provides direct digital control of
SED2 Variable Frequency Drives (VFDs). The LON
Interface resides on a L
L M products from multiple vendors.
ON ARK
Product Numbers
SED2-LONI/F, includes SED2 VFD LON Interface
Option, and CD-ROM with files and operating
instructions.
Warning/Caution Notations
Personal injury/loss of life may
WARNING:
occur if you do not perform a
procedure as specified.
CAUTION: Equipment damage, or loss of
data may occur if you do not
perform a procedure as specified.
Installation
SED2 VFD Frame Sizes A, B, and C
WARNING:
Make sure that the SED2 VFD is
de-energized (off) before you install or
remove the LON Interface Option.
1. Remove the SED2 VFD operator panel.
2. Install the LON Interface on the SED2 VFD I/O
module (Figure 1) by inserting two bottom guides
into appropriate slots at the sides of the I/O
module and pushing the upper section inward
until the locking mechanism latches.
3. Route the network cable (without connector) to
the LON Interface.
4. Terminate the end of network cable with a single,
two-pin, female L
ON
5. Attach the network cable FTT-10A connector to
connector at bottom of LON Interface (Figure 2).
Item Number 129-387, Rev. BA
W ® network with
ON ORKS
Works FTT-10A connector.
6. Reinstall SED2 VFD operator panel on LON
Interface.
L
ON
INTERFACE
OPTION
Figure 1. Installing LON Interface Option on SED2 VFD
Frame Sizes A, B, and C.
Figure 2. Network Connection on Bottom of
LON Interface Option.
Installation Instructions
Document No. 129-387
October 2, 2009
SED2
VFD
Page 1 of 3
