Tx650M - Corsair TXM Series Manual

TXM SERIES
™

TX650M

Dimensions:
150mm (W) x 86mm (H) x 140mm (L)
Package contents
• Corsair TXM Series power supply unit
• AC power cord
• DC Modular cable set
• DC Modular cable storage bag
Corsair TX650M power table
Model RPS0069
Part No.
CP-9020132 / 75-002624
AC input Rating 100 - 240V
Input Current 10A - 5A
Frequency 47 - 63Hz
Total Power: 650W
Corsair TX650M power supply efficiency
% EFFICIENCY
SYSTEM LOAD
Corsair TX650M power supply fan noise curve
Fan Noise (db)
Power Output - Watts
• Cable ties
• Corsair case badge
• User manual
Max Load Max Output
+3.3V 25A
130W
+5V
25A
+12V 51A 612W
-12V 0.8A 9.6W
+5Vsb 3A 15W
input 115Vac input 230Vac
7
Corsair TX650M DC cable listing
Qty Description
ATX Cable 24 Pin (20+4)
610mm 610mm
1
EPS/ATX12V 8 Pin (4+4) cable
650mm
1
650mm
PCIe 8 Pin (6+2) cable
600mm
600mm
2
SATA Cable
500mm 100mm
2 500mm 100mm
Peripheral Cable (4-Pin)
450mm 100mm 100mm
1
450mm 100mm 100mm
Floppy Adapter (4-Pin)
101mm
1
TXM SERIES
Total Length
Connectors Per Cable
1
610mm
(± 10mm)
Total Connectors
1
Connectors Per Cable
1
650mm
(± 10mm)
Total Connectors
1
Connectors Per Cable
2
750mm
(± 10mm)
Total Connectors
4
Connectors Per Cable
3
700mm
100mm
100mm
(± 10mm)
Total Connectors
6
Connectors Per Cable
4
750mm
100mm
100mm
(± 10mm)
Total Connectors
4
Connectors Per Cable
1
101mm
(± 5mm)
Total Connectors
1
8
™
