- Page 1 User’s Manual Corsair HX620W/HX520W Benutzerhandbuch Manuel d’utilisation du Corsair HX620W/HX520W Manuale utente Corsair HX620W/HX520W Corsair HX620W/HX520W Manual del Usuario Corsair HX620W/HX520W Modular Power Supply...
- Page 2 Corsair’s easily detachable and flexible modular cables allow you to use only the cables you need and enhance the air flow inside your system. The HX620W/HX520W is backed with a 5 year warranty and Corsair’s legendary customer service.
- Page 3 • Gold plated connectors provide oxide free ultra low-resistance contact between the power supply and critical system components. • 5 year warranty and lifetime access to Corsair’s legendary technical support and customer service. ■ Power Supply Specifications...
-
Page 4: Package Contents
■ Package Contents • Corsair HX620W/HX520W Power Supply unit with 24-pin main power connector, 4-pin +12V connector and 8-pin EPS12V connector. • User Manual • Corsair enhanced modular cable set, consisting of the following: – 2 x 800mm 4-pin peripheral power connector cables with three connector heads. - Page 5 Step A: Building a brand new system: (If you are replacing your existing power supply, please go to step B.) 1. Please make sure the HX620W/HX520W is not connected with an AC power cord. 2. Follow the directions in your chassis manual and install the HX620W/ HX520W with the screws provided.
- Page 6 6. Connect the AC power cord to the HX620W/HX520W and turn on the HX620W/HX520W by pushing the switch to "I" position. Congratulations! You have completed installation of the HX620W/HX520W power supply and your system is ready to go! Step B: Replacing your existing power supply 1.
- Page 7 Corsair HX620W/ HX520W series products, either due to mistake or omission on our part in the instructions, or due to failure or defect in the Corsair HX620W/HX520W series products. In addition, Corsair assumes no liability, expressed or implied, for the use of this product, and more specifically for any, and all damages...
- Page 8 EMAIL: www.corsairmemory.com WEB: Document Number: P49-00001 ©2006 Corsair Memory. The Corsair logo, HX620W Power Supply, and HX520W Power Supply are trademarks of Corsair Memory. All other names and products are trademarks and property of their respective owners. Printed in China.
