Product Information (cont.)
Pin Connectors (cont.)
PIN Name
36 USB_DN
37 GND
38 USB_DP
39 VCC_3V3
40 GND
41 VCC_3V3
42 LED_WWAN
43 GND
44 GPIO5
45 NC
46 UART_DTR
47 NC
48 V_BCKP
49 NC
50 GND
51 NC
52 VCC_3V3
8
Input/Output
Input/Output USB Data Negative
Power Ground
Input/Output USB Data Positive
Power Input
Power Ground
Power Input
Output Default: high impedance;
LED setting flash via AT command port
AT+UGPIOC=16,2
Power Ground
Input SIM detection
Not Connected
Input +1.8V UART data terminal ready
Not Connected
Input Real Time Clock Backup supply
Not Connected
Power Ground
Not Connected
Power Power Input
Cat M1 / NB-IoT Modem
Description
SARA-R4 pin42
SARA-R4 pin9
EVA-M8M-0 pin21
