Introduction

The NWK030 is based on the SARA-R410M module and provides a single RF interface for connecting the external antenna.
"Cellular" represents the primary RF input/output for transmission and reception of LTE RF signals. The "Cellular" pin of NWK030 has a
nominal characteristic impedance of 50 Ω and must be connected to the primary Tx / Rx antenna through a 50 Ω transmission line to
allow proper RF transmission and reception.
When installed in a OnLogic computer, the "Cellular" interface is connected to an external antenna mount. The external mount uses an
SMA (female) connector. Our line of compatible cellular antennas all use a standard SMA (male) connector.
4
Uplink Frequencies (MHz)
1850 - 1910
1710 - 1755
824 - 849
698 - 716
777 - 787
Cat M1 / NB-IoT Modem
Downlink Frequencies (MHz)
1930 - 1990
2110 - 2155
869 - 894
728 - 746
746 - 756
US Office
Phone: +1 802 861 2300
Email: info@onlogic.com
www.onlogic.com
NWK030
Maximum Antenna gain (dBi)
7
6.75
4.41
3.66
3.94
