ADT Safewatch Pro 3000 Programming Manual page 7

✱ 177 DEVICE DURATION 1, 2
(used in *80 Menu mode-Device Actions 5/6)
SYSTEM OPTIONS *180-*181
✱ 180 SINGLE ZONE BYPASS
✱ 181 50/60 HERTZ AC OPERATION
✱ 182 CONFIGURABLE ZONE TYPE 90
✱ 183 ZONE TYPE 90 REPORT CODES
IMPORTANT: Use existing Contact ID®
codes, if appropriate, or define unique codes
in CID code range 750-789. See important
note in installation instructions.
✱ 184 CONFIGURABLE ZONE TYPE 91
✱ 185 ZONE TYPE 91 REPORT CODES
IMPORTANT: Use existing Contact ID®
codes, if appropriate, or define unique codes
in CID code range 750-789. See important
note in installation instructions.
TOUCHPAD OPTIONS *190-*196 (NOTE : Options for touchpad address 16 are set by the factory and cannot be changed.)
NOTE: Each touchpad must be assigned a unique address. Touchpads programmed with the same address will give
unpredictable results.
∗190 TOUCHPAD 2 ADDRESS 17
∗191 TOUCHPAD 3 ADDRESS 18
∗192 TOUCHPAD 4 ADDRESS 19
∗193 TOUCHPAD 5 ADDRESS 20
∗194 TOUCHPAD 6 ADDRESS 21
∗195 TOUCHPAD 7 ADDRESS 22
∗196
TOUCHPAD 8 ADDRESS 23
∗197 EXIT TIME DISPLAY INTERVAL
∗198 DISPLAY PARTITION NUMBER
(for Custom Display Touchpads)
∗199 ECP FAIL DISPLAY
[0] [0]
1 2
[0]
[0]
1 2 3 4
Make the appropriate entry for each digit, 1-10, based on the charts provided on the
next page. Each digit's entry is the sum of the values of its selected options
(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).
UL: Do not configure zones as a fire alarm or UL burglar alarm zone.
90 ALARM ID: XXX
TROUBLE ID: XXX
1 2 3 4
Make the appropriate entry for each digit, 1-10, based on the charts provided on the
next page. Each digit's entry is the sum of the values of its selected options
(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).
UL: Do not configure zones as a fire alarm or UL burglar alarm zone.
91 ALARM ID: XXX
TROUBLE ID: XXX
[0] [0]
Part. Sound
[0] [0]
Part. Sound
[0] [0]
Part. Sound
[0] [0]
Part. Sound
[0] [0]
Part. Sound
[0] [0]
Part. Sound
[0] [0]
Part. Sound
[0]
[0]
[0]
– 7 –
0 = 15 seconds 6 = 2-1/2 min
1 = 30 seconds 7 = 3 min
2 = 45 seconds 8 = 4 min
3 = 60 seconds 9 = 5 min
4 = 90 seconds #+10 = 6 min
5 = 2 minutes
0 = disable; 1 = enabled
0 = 60 Hz; 1 = 50 Hz
5 6 7 8
Enter the desired 3-digit Contact ID
alarms and troubles occurring on zones assigned to
this zone type. Enter the codes sequentially (all 6
digits). When entering digits, [#] moves cursor back, [∗]
moves forward. Press [∗] when done to continue.
5 6 7 8
Enter the desired 3-digit Contact ID
alarms and troubles occurring on zones assigned to
this zone type. Enter the codes sequentially (all 6
digits). When entering digits, [#] moves cursor back, [∗]
moves forward. Press [∗] when done to continue.
Partition: 0 = keypad disabled; 1-3 = part. no. (3 = com)
Sound: 0 = no suppression
1 = suppress arm/disarm and E/E beeps
2 = Suppress chime beeps only
3 = suppress arm/disarm, E/E, and chime
beeps
See field ∗190 for entries.
See field ∗190 for entries.
See field ∗190 for entries.
See field ∗190 for entries.
See field ∗190 for entries.
See field ∗190 for entries.
0 = no display; 1-5 = seconds between display refresh
0 = no; 1 = yes (partition no. appears on Custom
Display)
0 = 3-digit display ("1" + device address)
1 = 2-digit fixed-display as "91"
#+11 = 7 min
#+12 = 8 min
#+13 = 10 min
#+14 = 12 min
#+15 = 15 min
9 10
report codes for
®
9 10
report codes for
®
