Figure 19 - The wiring page for the designed system with the outputs expanded.
If this wiring does not match how you would like to connect the system, you can click and drag audio channels on the
wiring page to move to different outputs to match your desired wiring. In this example, the wiring matches our desired
system and therefore no further changes are required on the wiring page.
Saving the SoundStructure System Project
Once the configuration changes have been made, it is important to save the project to disk to ensure the changes are
saved to the file that will ultimately be uploaded to the SoundStructure system. To save the file, navigate to the File
menu and select Save Project1 as shown in Figure 20.
Figure 20 - Navigating to the File Save menu.
Next enter the filename of the project and click Save as shown in Figure 21.
