Page 1
OPUS RolLAM 720, 380 Super • Instrukcja obsługi Instrukcja obsługi/ User Guide Opus MasterPress EMD OPUS RolLAM 720 Super Instrukcja OPUS RolLAM 380 Super MasterPress EMD Instrukcja obsługi laminatora...
ZASADY BEZPIECZEŃSTWA Przed rozpoczęciem pracy z urządzeniem należy uważnie zapoznać się z zasadami bezpieczeństwa, zaleceniami producenta i instrukcją obsługi. Instrukcję należy zachować i korzystać z niej w przypadku jakichkolwiek wątpliwości dotyczących obsługi urządzenia. • Urządzenie należy ustawić na stabilnym podłożu w pobliżu gniazdka o napięciu AC 220 –...
• Następnie nałóż laminator na stojak i całość skręć dołączonymi śrubami. *Dla modelu RolLam 380 Super stojak stanowi wyposażenie opcjonalne. **Do modelu RolLam 720 Super belka dołączona jest do urządzenia - nie ma jej w opakowaniu stojaka. BUDOWA URZĄDZENIA Construction of the device Obcinak Górna część...
Control panel When the machine is initially turned on, the LCD window will display the last working preset PANEL STEROWANIA memory setting. 1. TEMP – Regulacja temperatury TOP - górnego wałka BOTTOM - dolnego wałka 2. SPEED – Regulacja prędkości 3.
Page 5
5.Operation OPUS RolLAM 720, 380 Super • Instrukcja obsługi 1. Install the top and bottom film brackets. 2. Load the films. (The adhesive side facing the inside of roll = adhesive in) 5. Rolki napinacza ustaw w pozycji górnej. 6. Odwiń folię z górnej rolki.
Page 6
USTAWIENIE TEMPERATURY ORAZ PRĘDKOŚCI LAMINACJI 6. TEMPERATURE AND SPEED MEMORY SETTINGS Dla twojej wygody prędkość oraz temperaturę laminacji możesz ustawić za pomocą You can set the temperature and speed for your convenient work through MEMO butto przycisku MEMO. Urządzenie zostało fabrycznie zaprogramowane. Możesz zmienić...
Page 7
OPUS RolLAM 720, 380 Super • Instrukcja obsługi REKOMENDOWANE PARAMETRY LAMINACJI USTAWIENIA FOLIA OBIEKT Temperatura Prędkość Poniżej 50 μm poniżej 100 g 720 mm szerokości 3,0 m/min 50 μm 100 μm 2,7 m/min 100 μm 150 μm 2,2 m/min 150 μm 250 μm 1,1 m/min Poniżej 50 μm...
Page 8
problemów z urządzeniem. Z tego powodu wałki powinny być czyszczone często i regularnie. • Nie czyść wałków podczas ich obracania się. • Używaj do czyszczenia tylko delikatnych materiałów, wszystkie inne mogą uszkodzić powierzchnię wałków. • Nie pozwól, aby wałki były ściskane przez dłuższy czas, by uniknąć ich uszkodzenia. •...
Zapewniając prawidłową utylizację sprzętu pomagamy chronić środowisko naturalne. 15.04.2019 OPUS Sp. z o.o. ● ul. Toruńska 8 ● 44 – 122 Gliwice ● Poland ● www.opus.pl...
Page 11
OPUS RolLAM 720, 380 Super • Instrukcja obsługi Instrukcja obsługi/ User Guide Opus MasterPress EMD OPUS RolLAM 720 Super Instrukcja OPUS RolLAM 380 Super MasterPress EMD User guide...
HEALTH & SAFETY PRECAUTIONS Before operating the equipment, please read the Health & Safety precautions, manu- facturers recommendations and the operation manual. The manual should always be easily available at any time for the operator. • The equipment: should be protected against dust and moisture. •...
• Then put the laminator on the stand and fix together with the bolts supplied. * For the RolLam 380 Super, the stand is optional. ** For the RolLam 720 Super the crossbar is in the box with the device. CONSTRUCTION OF THE DEVICE...
Control panel CONTROL PANEL When the machine is initially turned on, the LCD window will display the last working preset memory setting. When the equipment is initially turned on, the LCD window will display the last working preset memory setting. 1.
Page 15
OPUS RolLAM 720, 380 Super • User guide 5. Raise the top roller using the tension handle. 6. Pull a length of film from the main carrier roller enough to feed through the rollers. 7. Insert the film between the tensioner rollers.
7. Set the temperature and Speed. 8. When "Ready" is displayed, paste the inserted the paper to the film. 9. Down the roller tension handle. Bottom film loading - follow the same way as the top film loading. 10. Set the Idle Bar_Anti Curling in the each steps for the material thickness Slitter Idle Bar-Table Perforator...
OPUS RolLAM 720, 380 Super • User guide ROLLER TENSION SETTINGS 7 ROLLER TENSION SETTINGS Attention: If you have finished laminating and do not want to use the laminator, insert a peace of scrap paper between the rollers, then put the roller tensioner handle to the Stand By position as image.
MAINTENANCE Open the rollers with the tension handle when not laminate for a long time. This will prevent the device from overheating. Remember to turn off after use. Working with one roll of laminating film or when the top and bottom rollers are not in the right position can leave the adhesive on the rollers which will affect the next lamination.
By ensuring proper disposal of equipment we are helping to protect the environment, humanity and wild life health. 15.04.2019 OPUS Sp. z o.o. ● ul. Toruńska 8 ● 44 – 122 Gliwice ● Poland ● www.opus.pl...
