Introduction

Congratulations on purchasing this Wireless Broadband Router. This Wireless Broadband Router
is a cost-effective IP Sharing Router that enables multiple users to share the Internet through an
ADSL or cable modem. Simply configure your Internet connection settings in the Wireless
Broadband Router and plug your PC to the LAN port and you're ready to share files and access
the Internet. As your network grows, you can connect another hub or switch to the router's LAN
ports, allowing you to easily expand your network. The Wireless Broadband Router is embedded
with a IEEE 802.11g/b MIMO access point that allows you to build up a wireless LAN. The
Wireless Broadband Router provides a total solution for the Small and Medium-sized Business
(SMB) and the Small Office/Home Office (SOHO) markets, giving you an instant network today,
and the flexibility to handle tomorrow's expansion and speed.

Features

High Internet Access throughput (50M)
Allow multiple users to share a single Internet line
Supports up to 253 users
Internet Access via Cable or xDSL modem
Access Private LAN Servers from the Public Network
Equipped with four LAN ports (10/100M) and one WAN port (10/100M)
Provides IEEE 802.11g/b MIMO wireless LAN access point
Support DHCP (Server/Client) for easy setup
Support advance features such as: Special Applications, DMZ, Virtual Servers, Access
Control, Firewall.
Allow you to monitor the router's status such as: DHCP Client Log, System Log, Security
Log and Device/Connection Status
Easy to use Web-based GUI for configuration and management purposes
Remote Management allows configuration and upgrades from a remote site (over the
Internet)

Minimum Requirements

One External xDSL (ADSL) or Cable modem with an Ethernet port (RJ-45)
Network Interface Card (NIC) for each Personal Computer (PC)
PCs with a Web-Browser (Internet Explorer 4.0 or higher, or Netscape Navigator 4.7 or
higher)

Package Content

One 4-port Broadband router unit
One Quick Installation Guide
One User Manual CD
One Power Adapter
Accessories

Note

The WAN "idle timeout" auto-disconnect function may not work due to abnormal activities of
some network application software, computer virus or hacker attacks from the Internet. For
example, some software sends network packets to the Internet in the background, even when
you are not using the Internet. So please turn off your computer when you are not using it. This
function also may not work with some ISP. So please make sure this function can work properly
when you use this function in the first time, especially your ISP charge you by time used.
