CLEARANCE
SPECIFICATIONS 3
Camshaft
End Play (with shim)
Running Clearance
Bore I.D.
New
Max. Wear Limit
Bearing Surface O.D.
New
Max. Wear Limit
Connecting Rod
Connecting Rod-to-Crankpin
Running Clearance @ 21°C
(70°F)
New
Max. Wear Limit
Connecting Rod-to-Crankpin
Side Clearance
Connecting Rod-to-Piston Pin
Running Clearance @ 21°C
(70°F)
Piston Pin End I.D. @ 21°C
(70°F)
New
Max. Wear Limit
Crankcase
Governor Cross Shaft Bore I.D.
New
Max. Wear Limit
Crankshaft
End Play (free)
Bore (in crankcase)
New
Max. Wear Limit
Bore (in oil pan)
New
Crankshaft to Sleeve Bearing
(oil pan) Running Clearance
New
Crankshaft Bore (oil pan)-to-
Crankshaft Running Clearance
New
Flywheel End Main Bearing
Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper Limit
Max. Out-of-Round Limit
Values are in Metric units. Values in parentheses are English equivalents.
3
5 Lubricate threads with engine oil prior to assembly.
24 690 31 Rev. D
PCV680, PCV740
0.101/0.406 mm (0.0040/0.0160 in.)
0.025/0.105 mm (0.001/0.004 in.)
20.000/20.025 mm (0.7874/0.7884 in.)
20.038 mm (0.7889 in.)
19.920/19.975 mm (0.7843/0.7864 in.)
19.914 mm (0.7840 in.)
0.043/0.073 mm (0.0017/0.0029 in.)
0.088 mm (0.0035 in.)
0.26/0.63 mm (0.0102/0.0248 in.)
0.015/0.028 mm (0.0006/0.0011 in.)
17.015/17.023 mm (0.6699/0.6702 in.)
17.036 mm (0.6707 in.)
8.025/8.075 mm (0.3159/0.3179 in.)
8.088 mm (0.3184 in.)
0.025/0.635 mm (0.001/0.025 in.)
40.972/40.997 mm (1.6131/1.6141 in.)
41.011 mm (1.6146 in.)
40.974/41.000 mm (1.6131/1.6141 in.)
0.03/0.12 mm (0.001/0.005 in.)
0.039/0.087 mm (0.0015/0.0034 in.)
40.913/40.935 mm (1.6107/1.6116 in.)
40.843 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
5 Lubricate threads with engine oil prior to assembly.
