Specifi cations
ENGINE IDENTIFICATION NUMBERS
Kohler engine identifi cation numbers (model, specifi cation and serial) should be referenced for effi cient repair,
ordering correct parts, and engine replacement.
Model . . . . . . . . . . . . . . . . . . . . .
Specifi cation . . . . . . . . . . . . . . .
Serial . . . . . . . . . . . . . . . . . . . . .
GENERAL SPECIFICATIONS
Bore
Stroke
Displacement
Oil Capacity (refi ll)
Maximum Angle of Operation
(@ full oil level) 4
TORQUE SPECIFICATIONS
Blower Housing
Into cored aluminum hole or weld nut
M5
M6
Into extruded hole in sheet metal
M5
M6
Connecting Rod
Cap Fastener (torque in increments)
6 mm straight shank
6 mm straight shank gray metallic color
Values are in Metric units. Values in parentheses are English equivalents.
3
Exceeding maximum angle of operation may cause engine damage from insuffi cient lubrication.
4
Lubricate threads with engine oil prior to assembly.
5
Any and all horsepower (hp) references by Kohler are Certifi ed Power Ratings and per SAE J1940 & J1995 hp
6
standards. Details on Certifi ed Power Ratings can be found at KohlerEngines.com.
6
Propane EFI Command Engine
Vertical Shaft
Numerical Designation
Year Manufactured Code
Code Year
46 2016
47 2017
48 2018
3,6
3,5
PCV680
PCV680-3001
4623500328
6.2 N·m (55 in. lb.) into new holes
4.0 N·m (35 in. lb.) into used holes
10.7 N·m (95 in. lb.) into new holes
7.3 N·m (65 in. lb.) into used holes
2.8 N·m (25 in. lb.) into new holes
2.3 N·m (20 in. lb.) into used holes
2.8 N·m (25 in. lb.) into new holes
2.3 N·m (20 in. lb.) into used holes
KohlerEngines.com
Factory Code
PCV680, PCV740
83 mm (3.27 in.)
69 mm (2.72 in.)
747 cc (45.6 cu. in.)
1.6-1.9 L (1.7-2.0 U.S. qt.)
25°
PCV680, PCV740
11.6 N·m (103 in. lb.)
13.6 N·m (120 in. lb.)
24 690 31 Rev. D
