Kohler Command PRO EFI PCV680 Service Manual page 10

Specifi cations
CLEARANCE
SPECIFICATIONS 3
Crankshaft (continued)
Oil Pan End Main Bearing
Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper Limit
Max. Out-of-Round Limit
Connecting Rod Journal
O.D. - New
O.D. - Max. Wear Limit
Max. Taper Limit
Max. Out-of-Round Limit
Crankshaft T.I.R.
PTO End, Crank in Engine
Entire Crank, in V-Blocks
Cylinder Bore
Bore I.D.
New
O.D. - Max. Wear Limit
Max. Out-of-Round Limit
Max. Taper
Cylinder Head
Max. Out-of-Flatness
Governor
Governor Cross Shaft -to-
Crankcase Running Clearance
Cross Shaft O.D.
New
Max. Wear Limit
Governor Gear Shaft -to-
Governor Gear Running
Clearance
Gear Shaft O.D.
New
Max. Wear Limit
Ignition
Spark Plug Gap
Crankshaft Position Sensor Air
Gap (only on earlier design
sensor bracket)
Crankshaft Position Sensor
Max. Air Gap (only on later
design sensor bracket)
Values are in Metric units. Values in parentheses are English equivalents.
3
10
PCV680, PCV740
40.913/40.935 mm (1.6107/1.6116 in.)
40.843 mm (1.608 in.)
0.022 mm (0.0009 in.)
0.025 mm (0.0010 in.)
35.950/35.973 mm (1.4153/1.4163 in.)
35.941 mm (1.415 in.)
0.018 mm (0.0007 in.)
0.025 mm (0.0010 in.)
0.279 mm (0.0110 in.)
0.10 mm (0.0039 in.)
83.006/83.031 mm (3.2680/3.2689 in.)
83.081 mm (3.2709 in.)
0.120 mm (0.0047 in.)
0.05 mm (0.0020 in.)
0.01 mm (0.004 in.)
0.025/0.126 mm (0.0009/0.0049 in.)
7.949/8.000 mm (0.3129/0.3149 in.)
7.936 mm (0.3124 in.)
0.090/0.160 mm (0.0035/0.0063 in.)
5.990/6.000 mm (0.2358/0.2362 in.)
5.977 mm (0.2353 in.)
0.76 mm (0.030 in.)
0.2-0.7 mm (0.008-0.027 in.)
2.794 mm (0.110 in.)
KohlerEngines.com 24 690 31 Rev. D
