Topcom Baby Viewer 2500
3.2 Baby unit
18. Night Light
19. Night Light button
20. Microphone
21. Support
22. Lens
23. Infrared LED's
24. Power indicator LED
4

Getting started

4.1 Baby unit battery Installation
The camera uses either 4 AAA - Size batteries (alkaline batteries recommended) or the
household AC current. The Baby unit has no charging function.
1. Loosen the screw in a counter clockwise direction using a small screw driver. Remove
the battery cover.
2. Install 4 'AAA' alkaline or rechargeable batteries following the polarity as shown. Close
the battery compartiment.
3. Slide the Power switch (26) to the ON position. The LED (24) on top of the camera
should light up green.
Slide the Power switch (26) to the OFF position to turn off the baby unit.
When the light is RED, the batteries are low and needs to be replaced.
Do not mix old batteries with new ones.
Keep batteries away from small children.
Do not short-circuit & dispose of in fire.
Remove the batteries if this device is not going to be used for a long period.
4
25. Antenna
26. On/Off switch
27. DC power adapter Jack
28. Battery cover
29. Speaker
30. Babybed fastener
2
2
1
1
3
3
