Do you have a question about the Celine and is the answer not in the manual?

Questions and answers

Anita Davis
May 9, 2025

I can't get the bobbin case back in after cleaning

1 comments:
Mr. Anderson
May 19, 2025

To reinsert the bobbin case in the EverSewn Celine sewing machine after cleaning:

1. Remove any thread caught in the hook area.
2. Turn the handwheel backward and forward by hand to clear any remaining thread.
3. Place the bobbin correctly into the bobbin case.
4. Ensure the thread stays along the designated path, including the tiny plastic knobs.
5. Reinsert the bobbin case into the machine securely.

Make sure the bobbin is threaded correctly and the case clicks into place.

This answer is automatically generated

Emilie
May 21, 2025

I have a Celine machine. What double needle is appropriate for it?

Emilie
May 21, 2025

What double needle should I order

Subscribe to Our Youtube Channel

Summary of Contents for EverSewn Celine

  • Page 3 SYMBOL INSTRUCTIONS Raise needle Raise presser foot Lower presser foot...
  • Page 4: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS IMPORTANT When using an electrical machine, basic safety precautions should always be followed, including the following: Please read the instruction manual carefully before using this machine. Keep the instruction manual at a suitable place with the machine and hand it over if you give the machine to a third party.
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS 10. Do not pull or push the fabric while sewing. This can result in needle breakage. 11. Switch the machine off ("O") when making any adjustments in the needle area, such as threading or changing the needle, threading the bobbin, or changing the presser foot, and the like.
  • Page 6 IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS! Attention! - This machine is intended for household use only. If used intensively or commercially, regular cleaning and especially attentive care is required. - Signs of wear and tear owing to intensive or commercial use are not covered automatically, even if they occur within the warranty period.
  • Page 7: Table Of Contents

    CONTENTS PRINCIPAL PARTS OF THE MACHINE ........... 6 MACHINE CONTROL BUTTONS .
  • Page 8 CONTENTS NEEDLE POSITION AND STITCH LENGTH ..........38 ZIGZAG STITCHES .
  • Page 9: Principal Parts Of The Machine

    PRINCIPAL PARTS OF THE MACHINE Bobbin winder spindle Stitch pattern plate Bobbin winder stopper Tension dial Speed limiting adjustment lever Presser foot pressure LCD screen Face plate Function buttons Operation buttons Memory buttons Thread cutter Selection buttons Buttonhole lever Function buttons Auto needle threader Needle plate cover Sewing table and...
  • Page 10: Machine Control Buttons

    MACHINE CONTROL BUTTONS A. Operation buttons (see page 28/29/30) 1. Start/stop button Press this button to start or stop the machine. 2. Thread cutter button Press this button after finishing sewing and the machine will trim the threads. 3. Reverse button Hold down this button to sew stitches in reverse or sew reinforcement stitches at a low speed.
  • Page 11: Function Buttons

    MACHINE CONTROL BUTTONS B. Function buttons (see page 31/32/33) 7. Stitch length adjustment buttons Press this button to adjust the length of the stitch. 8. Stitch width adjustment buttons Press this button to adjust the width of the zigzag stitch. Mode selection button Press this button to select direct mode, utility and decorative pattern mode and block letter mode.
  • Page 12: Lcd Screen

    LCD SCREEN Direct Pattern Suggested Needle position Pattern presser foot Bobbin winding Buttonhole lever Direct mode Mirror Needle up Pattern number Auto-lock Reverse Stitch length Stitch width Pattern Suggested Pattern presser foot Memory mode Total number of unit Pattern mode Number of current unit Auto-stop Pattern number...
  • Page 13: Pattern Chart

    PATTERN CHART The portions marked in gray (on the chart below) show the single unit of each stitch. Patterns Direct Patterns-10 Patterns-100 05 06 07 08 09 10 11 12 24 25 26 27 28 29 30 31 32 33 34 35 37 38 42 43 46 47...
  • Page 14: Accessories

    ACCESSORIES Standard All purpose foot Zipper foot Buttonhole foot Overcasting foot Blind hem foot Satin stitch foot Button sewing foot Brush/ Seam ripper Spool holder Edge/quilting guide Bobbin (3x) Screwdriver (L & S) Pack of needles Spool pin felt Auxiliary spool pin Soft cover Optional Cording foot...
  • Page 15: Connecting The Machine To The Power Source

    CONNECTING THE MACHINE TO THE POWER SOURCE Caution: Always make sure that the machine is unplugged from power source and the main switch is on "O" when the machine is not in use and before inserting or removing parts. Connecting the machine Before connecting the power supply, make sure that the voltage and frequency shown on the machine is conforming with your electrical power.
  • Page 16: Winding The Bobbin

    WINDING THE BOBBIN Bobbin winding Place the thread and spool holder onto the spool pin. For larger spools of thread, place the large side of the spool holder toward the spool. For smaller spools of thread, place the small side of the spool holder toward the spool, or use the small spool holder.
  • Page 17: Winding The Bobbin

    WINDING THE BOBBIN When the bobbin winder spindle is pushed to the right, which is the "bobbin winding position", the symbol " " appears on the LCD screen. The symbol will disappear from the LCD screen when the bobbin winder spindle is pushed to the left, which is the "sewing position".
  • Page 18: Inserting The Bobbin

    INSERTING THE BOBBIN Attention: Turn power switch to off ("O") before inserting or removing the bobbin. When inserting or removing the bobbin, the needle and presser foot must be fully raised. 1 Insert the bobbin in the bobbin case with the thread running in a counterclockwise direction (arrow).
  • Page 19: Threading The Upper Thread

    THREADING THE UPPER THREAD Please Note: It is important to carry out the threading correctly as by not doing so several sewing problems could result. Start by raising the needle to its highest point, and also raise the presser foot to release the tension discs. 1 Lift up the spool pin.
  • Page 20: Threading The Upper Thread

    THREADING THE UPPER THREAD 3 Guide the thread around the thread guide pulling the thread through the pre-tension spring as illustrated. 4. Thread the tension module by passing the thread between the silver discs. 5. Then, down and around the check spring holder. 6.
  • Page 21: Using The Needle Threader

    USING THE NEEDLE THREADER Attention: Turn power switch to the off position ("O"). Raise the needle to its highest position and lower the presser foot. 1 Lower the needle threader lever slowly and draw the thread through the thread guide as illustrated and then to the right.
  • Page 22: Drawing Up The Lower Thread

    DRAWING UP THE LOWER THREAD 1 Hold the upper thread with the left hand. Turn the handwheel towards you (counterclockwise) lowering, then raising the needle. 2 Gently pull on the upper thread to bring the bobbin thread up through the needle plate hole.
  • Page 23: Two-Step Presser Foot Lifter

    TWO-STEP PRESSER FOOT LIFTER The presser foot lifter raises and lowers the presser foot. When sewing several layers or thick fabrics, the presser foot can be raised a second stage for easy positioning of the work. ADJUSTING PRESSER FOOT PRESSURE The presser foot pressure of the machine has been pre-set and requires no particular readjustment according to the type of fabric...
  • Page 24: Starting Sewing

    STARTING SEWING Start/stop button The Start/Stop button can be used to run the machine when the foot controller is unplugged from the machine. Press the button to start sewing, then press it again to stop sewing. The machine will run slowly at the start of sewing. The speed limiting adjustment lever can control the sewing speed.
  • Page 25: Thread Tension

    THREAD TENSION - Basic thread tension setting is "4". To increase the tension, turn the dial to the next number up. To decrease the tension, turn the dial to the next number down. - Proper setting of tension is important for good sewing. There is no single tension setting appropriate for all the stitch functions and fabrics.
  • Page 26: Changing The Presser Foot

    CHANGING THE PRESSER FOOT Attention: Turn power switch of off ("O") position when carrying out any of the operations shown below. Attaching the presser foot holder Raise the presser foot bar (a) by raising the presser foot lifter. Attach the presser foot holder (b) as illustrated.
  • Page 27: Presser Foot Chart

    PRESSER FOOT CHART (The twin needle can be used for some stitches, offering more stitching options. For more information, go to the section: USING THE TWIN NEEDLE) PRESSER FOOT APPLICATION NEEDLE PRESSER FOOT APPLICATION NEEDLE General sewing, Satin stitch sewing Patchwork stitches, Decorative stitching, Smocking, Fagoting,...
  • Page 28: Matching Needle/ Fabric/ Thread

    MATCHING NEEDLE/ FABRIC/ THREAD NEEDLE, FABRIC, THREAD SELECTION GUIDE NEEDLE SIZE FABRICS THREAD 65/9-75/11 Lightweight fabrics-thin cottons, voile, Light-duty thread in cotton, nylon, silk, muslin, interlocks, cotton knits, polyester or cotton wrapped tricot, jerseys, crepes, woven polyester, polyester. shirt & blouse fabrics. 80/12 Medium weight fabrics-cotton, satin, Most threads sold are medium...
  • Page 29: Replacing The Needle

    REPLACING THE NEEDLE Attention: Turn power switch of off ("O") position when carrying out any of the operations shown below. Change the needle regularly, especially if it is showing signs of wear and causing problems. Insert the needle following the illustrated instructions.
  • Page 30: Pattern Balance Adjustment

    PATTERN BALANCE ADJUSTMENT If decorative stitch patterns, letter, numbers or the manual buttonhole are uneven when sewn on a particular fabric, adjust them with the pattern adjustment dial. – Use a screwdriver to turn the dial slightly toward the "+" or " ". The pattern adjustment dial normally should be in the horizontal position.
  • Page 31: Operation Buttons

    OPERATION BUTTONS Needle up/down position button Auto-lock button Reverse button Thread cutter button Start/stop button Start/stop button The machine will start running when start/stop button is pressed and will stop when pressed the second time. The machine will rotate slowly at the beginning of sewing.
  • Page 32: Reverse Button

    OPERATION BUTTONS Reverse button When the Direct Patterns 1-5 and Patterns 00- 05 are selected. Reverse is pressed to sew in reverse. An arrow " " will be shown in the LCD when the function is active. If you press and hold the Reverse button the machine will sew backwards until you release the button.
  • Page 33: Needle Up/Down Position Button

    OPERATION BUTTONS Needle up/down position button The machine automatically stops sewing with the needle in the up position. The Needle up/down position button offers the option of stopping with the needle in the up position or down in the material. Pressing the Needle up/down position button will raise or lower the needle.
  • Page 34: Function Buttons

    FUNCTION BUTTONS Stitch length adjustment buttons Stitch width adjustment buttons Mirror button Mode selection button Stitch width adjustment button When you select a stitch, the machine will automatically set the recommended stitch width, which will be indicated by numbers on the LCD screen.
  • Page 35: Stitch Length Adjustment Button

    FUNCTION BUTTONS Stitch length adjustment buttons When you select a stitch the machine will automatically set the recommended stitch length which will be indicated by numbers on the LCD screen. The stitch length can be adjusted by pressing the stitch length adjustment buttons.
  • Page 36: Mirror Button

    FUNCTION BUTTONS Mirror button (see page 64) The Direct Patterns 1-7 and Patterns 00-14, 27-99 can be mirror imaged along a vertical axis by pressing the " " button. The machine will continue to sew the reflected pattern until the mirror button is pressed again.
  • Page 37: Memory Buttons

    MEMORY BUTTONS Clear button Arrow button Memory button Memory button Press the " " button to enter the memory mode, and store the combinations of characters or decorative stitches. Press the " " button again to leave the memory mode and return Direct mode. Please Note: The Direct Patterns and Patterns 15-26 cannot be memorized.
  • Page 38: Selection Buttons

    SELECTION BUTTONS Direct pattern selection and number buttons Direct pattern selection and number buttons Direct pattern selection Press the buttons to select the utility patterns shown beside the number button when the mode button is set at the Direct mode. Number buttons Press the number buttons for selecting the pattern needed.
  • Page 39: Sewing Tips

    SEWING TIPS Sewing corners 1. Stop the sewing machine when you reach a corner. 2. Lower the needle into the fabric manually or by pressing the needle up/ down button once. 3. Raise the presser foot. 4. Use the needle as a pivot and turn the fabric.
  • Page 40: Installing The Extension Table

    SEWING TIPS Installing the extension table * The Extension Table is an optional accessory. 1. Pull the sewing table and accessory box off by sliding it to the left. 2. Follow the arrow, and stretch the foot of the extension table. 3.
  • Page 41: Needle Position And Stitch Length

    NEEDLE POSITION AND STITCH LENGTH Changing the needle position These setting apply only to Direct Patterns 1-4 and Patterns 00-04 . The pre-set position is "3.5", center – position. When you press the " " of stitch width adjustment button, the needle position will be moved to the left.
  • Page 42: Stretch Stitches

    STRETCH STITCHES Stretch stitches are strong and flexible and will give with the fabric without breaking. Good for Stretch stitches easy to ravel and knit fabrics. It is good for joining durable fabric such as denims. These stitches can also be used as a decorative top stitch.
  • Page 43: Overcasting Stitches

    OVERCASTING STITCHES Using the overcasting foot 5.0~7.0 2.0~3.0 1 Change the presser foot to the overcasting foot. 2 Sew the fabric with the fabric edge against the guide of the overcasting foot. Attention: The overcasting foot should be used to sew with Patterns 05 and 08 only. Do not set the stitch width narrower than "5.0", as it is possible that the needle could hit the presser foot and break when sewing other patterns and width settings.
  • Page 44: Blind Hems

    BLIND HEMS Blind hem for woven fabrics Blind hem for stretch fabrics 2.5~4.0 1.0~2.0 Please Note: It takes practice to sew blind hems. Always make a sewing test first. Fold the fabric as illustrated with the wrong side uppermost. Reverse Reverse Overcasting side...
  • Page 45: Button Sewing

    BUTTON SEWING 2.5~4.5 Select the pattern 26 to get the button sewing stitch. Change the presser foot to the button sewing foot. Move the drop feed lever to " " to lower the feed dogs. Position the work under the foot. Place the button in the desired position, lower the foot.
  • Page 46: Buttonhole Sewing

    BUTTONHOLE SEWING For light to medium weight fabrics 2.5~7.0 0.3~1.0 For light or medium weight fabrics For heavier weight fabrics 2.5~5.5 0.3~1.0 For light or medium weight fabrics For heavy weight fabrics 5.5~7.0 0.3~1.0 For jeans or stretch fabric with a coarse weave For stretch fabric 3.0~7.0...
  • Page 47 BUTTONHOLE SEWING Select the buttonhole stitch. Adjust the stitch width and the stitch length to the desired width and density. Position the fabric under the presser foot so that the centerline's mark is aligning with the center of the buttonhole foot. Starting point Lower the buttonhole lever, making sure it is...
  • Page 48 BUTTONHOLE SEWING 6 Buttonholes are sewn from the front of the presser foot to the back, as shown. 7 Cut the center of the buttonhole being careful not to cut any stitches on either side. Use a pin as a stopper at the bar tack so you do not cut too much.
  • Page 49: Making Corded Buttonholes

    BUTTONHOLE SEWING Making corded buttonholes When sewing corded buttonholes, hook a heavy thread or cord under the buttonhole foot. Attach the buttonhole foot and hook the gimp thread onto the back of the presser foot. Bring the two gimp thread ends to the front of the foot and insert them into the grooves, then temporarily tie them there.
  • Page 50: Bar Tack Stitch

    BAR TACK STITCH 1.0~3.0 0.5~1.0 1 Select the pattern 25 to get the bar tack stitch. Change the presser foot to the buttonhole foot. 2 Pull the button holder to the rear. Set the button guide plate on the buttonhole foot to the desired length.
  • Page 51: Eyelet Stitch

    EYELET STITCH 5.0 6.0 7.0 1 Select the pattern 22 to get the eyelet stitch. Attach presser the foot "A". – 2 Press the " " or " + " stitch width adjustment to button select the eyelet size. Size of eyelet. A.
  • Page 52: Darning Stitch

    DARNING STITCH 3.5~7.0 1.5~2.0 1 Select the pattern 23 or 24 to get the darning stitch. Change the presser foot to the buttonhole foot. 2 Baste the upper fabric and the reinforcement fabric together. Select the width of the pattern by using the stitch width button. Lower the presser foot over the center of the tear.
  • Page 53: Darning Stitch

    DARNING STITCH 5 Position the fabric so that the needle is 2mm (1/16 inch) in front of the area to be darned, and then lower the presser foot lever. Please Note: When lowering the presser foot, do not push in the front of the presser foot, otherwise the darning will not be sewn with the correct size.
  • Page 54: Zipper Insertion

    ZIPPER INSERTION Attention: Zipper foot should be used with machine set for straight stitch only. Care 1.5~3.0 should be given when choosing needle position as the needle could hit the presser foot and break when sewing with an altered Inserting a centered zipper needle position or with any other pattern.
  • Page 55: Inserting A Lapped Zipper

    ZIPPER INSERTION Inserting a lapped zipper 1 Baste the zipper opening on the garment. 2 inch 2 Fold back to the left seam allowance. Turn under the right seam allowance to form 3mm (1/8 inch) fold. 3 Attach the zipper foot. Attach the right side of the presser foot pin to the holder when sewing the left side of the zipper.
  • Page 56: Narrow Hemming

    NARROW HEMMING * The Rolled hem foot is an optional accessory. 1.5~3.0 1 Fold the edge of the fabric over about 3mm (1/8 inch), then fold it over again 3mm (1/8 inch) for about 5cm (2 inches) along the edge of the fabric. 2 Insert the needle into the fold by rotating the handwheel toward you, and lower the presser foot.
  • Page 57: Cording

    CORDING Sew over one, two or three strands of cord to embellish fabrics. Pearl cotton, embroidery floss or fine wool yarn can be used for cording. Single cording * The Cording foot is an optional accessory. Mark the design on the fabric. Insert the cord in the center groove of the cording foot from the right side opening.
  • Page 58: Satin Stitch Sewing

    SATIN STITCH SEWING 2.5~7.0 0.3~1.0 Use the satin stitch foot for satin stitching and sewing decorative stitches. This foot has a groove on the underside which allows dense stitching to pass freely underneath. To change the satin or decorative stitch pattern, you may adjust the length and width of the pattern by pressing the stitch length and width adjustment buttons.
  • Page 59: Edge/Quilting Guide

    EDGE/QUILTING GUIDE 1.0~3.0 * The Quilting foot is an optional accessory. Insert the edge/quilting guide in the presser foot holder as illustrated and set the space as you desire. Sew the first row and move over the fabric to sew successive rows with the guide riding along the previous row of stitching.
  • Page 60: Gathering

    GATHERING * The Gathering foot is an optional accessory. Gathered fabric Remove the presser foot holder and attach the gathering foot. Place fabric to be gathered under the presser foot. Sew a row of stitching. The stitches will automatically cause the fabric to gather. Adjust the upper thread tension dial to achieve the amount of fullness desired.
  • Page 61: Smocking

    SMOCKING 1 Use the all purpose foot to sew straight lines 1cm (3/8") apart, across the area. It may be helpful to reduce the needle thread tension slightly, so that the bobbin thread may be drawn later to gather the fabric. 2 Knot the threads along one edge.
  • Page 62: Free Motion Sewing

    FREE MOTION SEWING * The Darning foot is an optional accessory. 3.5~5.0 Move the drop feed lever to " " to lower the feed dogs. Remove the presser foot holder, and attach the darning foot to the presser foot holder bar. The lever (a) should be behind the needle clamp screw (b).
  • Page 63: Embroidery

    FREE MOTION SEWING Embroidery Stitch along the outline of the design by moving the embroidery hoop. Select zigzag stitch pattern and adjust the stitch width as desired. When sewing, make sure to maintain a constant speed. Fill in the design working from the outline towards the inside.
  • Page 64: Walking Foot

    WALKING FOOT * The Walking foot is an optional accessory. Please Note: Always try to sew first without the walking foot accessory which should be used only when necessary. It is easier to guide the fabric and you have a better view of the seam when using the standard, regular foot on your machine.
  • Page 65: Fagoting

    FAGOTING 1 Separate the folded edges of the fabric pieces with a gap of 4mm (1/8 inch) and baste them onto a piece of thin paper or water-soluble stabilizer sheet. Thin paper Basting 2 Align the center of the presser foot with the center of the two pieces of fabric and begin sewing.
  • Page 66: Scallop Stitch

    SCALLOP STITCH Scallop hem 1 Fold the fabric, right sides together. Sew along the folded edge, as illustrated. 2 Cut the fabric along the seam leaving an allowance of 3mm (1/8 inch) for seaming. Wrong side of fabric Notch the allowance. 3 Turn fabric over and push out the curved seam to the surface and press it.
  • Page 67: Mirror Image

    MIRROR IMAGE Please Note: - The Direct Patterns 8,9,0 and Patterns 15-26 cannot be mirror imaged. - Mirror imaged patterns can also be combined with other patterns. 1 Select the pattern. 2 Pressing the mirror button. 3 The LCD screen icon for mirror imaging of the pattern appears.
  • Page 68: Using The Twin Needle

    USING THE TWIN NEEDLE * The twin needle is an optional accessory. Please Note: When using twin needles, use the " T " presser 2.0~5.0 foot regardless of what kind of sewing will be carried out. 1 Insert the twin needle. Attention: When using twin needles, use the all purpose foot (T) regardless of what kind of sewing foot will be carried out.
  • Page 69: Memory

    MEMORY Combined patterns can be stored for later use. Since stored patterns are not lost after the sewing machine is turned off, they can be recalled at any time. This is convenient for patterns such as names, which may be used frequently. Please Note: The machine has a program memory that can retain 30 units of stitches.
  • Page 70: Adding Patterns Or Letters

    MEMORY Press the " " button to leave the memory mode and return to the Direct mode. Attention: The selected pattern will be cleared from the memory module after closing the machine if you do not press the " " button again when you have completed your selection.
  • Page 71: Warning Animation Message Display

    MEMORY Press foot controller. The machine will start to sew from first entered pattern. On the LCD screen, sewing stitch data is indicated. If you wish to check what is programmed or if you wish to start sewing a few stitches in the memory mode , use the "...
  • Page 72: Warning Functions

    WARNING FUNCTIONS Instruction message display Lowering the buttonhole lever When you select any buttonhole pattern or darning pattern, LCD screen will show the figure " ". It is to remind you to lower the buttonhole lever. Bobbin winding When the bobbin winder spindle is activated for bobbin winding (in the rightmost position) this figure appears on the LCD screen as a reminder.
  • Page 73: Buzzer Sound

    BUZZER SOUND Sound on Press on the stitch width button " " and turn on the power switch, the sound on mode will be set. Sound off Press on the stitch width button " " and turn on the power switch, the sound off mode will be set.
  • Page 74: Maintenance

    MAINTENANCE Attention: Disconnect the power cord from the wall socket before cleaning the screen and sewing machine surface, otherwise injury or electrical shock may result. Cleaning the screen If the front panel is dirty, wipe it gently with a soft, dry cloth. Do not use any organic solvents or detergents.
  • Page 75: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE Before calling for service, check the following items. If the problem still persists, contact the place of purchase or your nearest authorized dealer. Problem Cause Correction Reference 1.The machine is not threaded correctly. 1.Rethread the machine. Page 16 2.The thread tension is too tight.
  • Page 76: Trouble Shooting Guide

    TROUBLE SHOOTING GUIDE Problem Cause Correction Reference 1.The needle thread tension is too tight. 1.Loosen the thread tension. Page 22 2.The needle thread is not threaded 2.Rethread the machine. Page 16 correctly. Seam 3.The needle is too heavy for the fabric 3.Choose a needle to suit the thread and Page 25 puckering...
  • Page 77 Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.
  • Page 80 021H7A0112(EN)
