TL-FO2-VLC User Manual Preface Read this user manual carefully before using this product. Pictures shown in this manual are for reference only; the actual product may vary. This manual is only for operation instruction only and not for any maintenance or repair.
TL-FO2-VLC User Manual SAFETY PRECAUTIONS To insure proper operation, please read all instructions carefully before using the device. Save this manual for further reference. l Unpack the equipment carefully and save the original box and packing material for possible future shipment l Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons.
10km over fiber optic cable. In addition to 4K/60 video with multichannel audio, the TL-FO2-VLC supports HDR, RGB, and YCbCr 4:4:4 color spaces. When the video signal bandwidth exceeds 9 Gpbs, the video scaling processor will dynamically scale the content for a visually lossless viewing experience.
TL-FO2-VLC User Manual 2. Panel Description 2.1 Transmitter Name Description RS232 RS232 control connector Firmware Mini-USB connection for firmware updates only Mode DIP switches for operation modes – see Sec RED: Power LED Indicator Power/Link Indicators GREEN: Fiber optic link indicator Optical SFP+ module port –...
TL-FO2-VLC2 User Manual 2.2 Receiver Name Description RS232 RS232 control connector Firmware Mini-USB connection for firmware updates only Mode DIP switches for operation modes – see Sec. 4 RED: Power LED Indicator Power/Link Indicators GREEN: Fiber optic link indicator Optical SFP+ module port –...
For two-way IR control of connected sources and displays from either location, first, connect IR Emitters to the IR OUT ports of the TL-FO2-VLC transmitter (TX) and TL-FO2-VLC receiver (RX), and then insert IR Receivers into the IR IN ports of the TL-FO2-VLC transmitter (TX) and TL-FO2-VLC receiver (RX).
TL-FO2-VLC2 User Manual 5. RS232 Pinout The TL-FO2-VLC allow bidirectional RS232 to pass between the Tx and Rx. Signal pin assignments for both the transmitter and receiver are shown in the following table: 6. Specification Transmitter Input/Output HDMI Input 1 HDMI Receptacle – Type A Female...
Page 10
Diagnostic LEDs Link and Power Included Accessories TL-FO2-VLC-MM: Receiver (1 ea), Transmitter (1 ea), 12V 2A DC Power Supply (2 ea), IR Receiver (1 ea), IR Transmitter (1ea), TL-10GSFPP-MM300 (2 ea) TL-FO2-VLC-SM: Receiver (1 ea), Transmitter (1 ea), 12V 2A DC Power Supply (2 ea), IR Receiver (1 ea), IR Transmitter (1ea), TL-10GSFPP-SM10K (2 www.tlnetworx.com...
TL-FO2-VLC2 User Manual 8. Troubleshooting & Maintenance l No image on display: l Ensure that the display device has been set to the correct input. l Ensure that the HDMI cables used for both the source/transmitter and the receiver/display are properly connected and are working. Test the HDMI cables directly from a source to display and ensure their operation.
TL-FO2-VLC2 User Manual 9. After-sales Service 1) Product Limited Warranty: We warrant that our products will be free from defects in materials and workmanship for three years. 2) Warranty coverage may be voided when: l The warranty period has expired l The factory applied serial number has been altered or removed from the product l There is damage, deterioration or malfunction caused by: l Atypical wear and tear...
