- Page 1 User Manual TL-TP70-HDIR 70m Extender with ARC and IR All Rights Reserved Version: TL-TP70-HDIR_160708...
- Page 2 TL-TP70-HDIR User Manual Preface Read this user manual carefully before using this product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. Trademarks Product model and logo are trademarks. Any other trademarks mentioned in this manual are acknowledged as the properties of the trademark owner. No part of this publication may be copied or reproduced without prior written consent. FCC Statement This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. It has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a commercial installation. Operation of this equipment in a residential area is likely to cause interference, in which case the user at their own expense will be required to take whatever measures may be necessary to correct the interference Any changes or modifications not expressly approved by the manufacture would void the user’s authority to operate the equipment. www.tlnetworx.com...
- Page 3 TL-TP70-HDIR User Manual SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. l Unpack the equipment carefully and save the original box and packing material for possible future shipment l Follow basic safety precautions to reduce the risk of fire, electrical shock and injury to persons. l Do not dismantle the housing or modify the module. It may result in electrical shock or burn. l Using supplies or parts not meeting the products’ specifications may cause damage, deterioration or malfunction. l Refer all servicing to qualified service personnel. l To prevent fire or shock hazard, do not expose the unit to rain, moisture or install this product near water. l Do not put any heavy items on the extension cable in case of extrusion. l Do not remove the housing of the device as opening or removing housing may expose you to dangerous voltage or other hazards. l Install the device in a place with fine ventilation to avoid damage caused by overheat. l Keep the module away from liquids. l Spillage into the housing may result in fire, electrical shock, or equipment damage. If an object or liquid falls or spills on to the housing, unplug the module immediately. l Do not twist or pull by force ends of the optical cable. It can cause malfunction. l Do not use liquid or aerosol cleaners to clean this unit. Always unplug the power to the device before cleaning.
-
Page 4: Table Of Contents
TL-TP70-HDIR User Manual Contents 1. Introduction .......................... 1 1.1 Introduction to TL-TP70-HDIR .................. 1 1.2 Features ........................... 1 1.3 Package List ........................ 1 2. Panel Description ........................ 2 2.1 HDBaseT Transmitter ....................... 2 2.2 HDBaseT Receiver .............. E rror! Bookmark not defined. 3. System Connection ........................ 4 3.1 Usage Precautions ...................... 4 3.2 System Diagram ....................... 4 3.3 Connection Procedures .................... 4 3.4 PoC Solution ........................ 5 3.5 ARC Solution . -
Page 5: Introduction
TL-TP70-HDIR User Manual 1. Introduction 1.1 Introduction to TL-TP70-HDIR The TL-TP70-HDIR is an ultra thin design extender set consisting of a transmitter and a receiver. Using HDBaseT technology, the set transmits a 1080p signal to the receiver up to 70m via a shielded Cat5e/Cat6 cable. Bi-directional IR communication is included to allow control of an IR source or display. PoC power allows you to connect the power supply at either the transmitter or the receiver to power both units. The set also supports ARC, which enables audio up streaming from display to an audio system using either HDMI or the coax digital output. 1.2 Features l HDMI1.4 compliant, supports resolutions up to 4Kx2K l Maximum transmission distance is 70m for 1080p and 40m for 4Kx2K over a single shielded CAT5e/CAT6 cable l High Bandwidth: 10.2Gps. l Compliant with HDCP1.4 l Uses HDBaseT technology for reliability and features l Supports bi-directional PoC l Supports ARC on HDMI or coax digital output l Bi-directional IR control 1.3 Package List 1 x TL-TP70-HDIR (including TX and RX) ²... -
Page 6: Panel Description
TL-TP70-HDIR User Manual 2. Panel Description 2.1 HDBaseT Transmitter Front LINK HDCP Rear Bottom ARC MODE Figure 2- 1 Panel Description of TX No. Name Description HDBT Link status indicator, lights when the transmitter & receiver are linked and LINK communicating HDCP compliant indicator Ø Lights when input signal is HDCP encrypted HDCP Ø Blinks when the input signal is not HDCP encrypted Ø Turns off when there is no input Power Illuminates red when the unit is powered on ARC Output port for ARC audio Connect the included 5V IR Receiver (with carrier) to receive infrared signal, it will IR IN output at the RX IR OUT Connect the included 5V IR Emitter and attach to the IR window of the device you IR OUT wish to control. HDMI IN... -
Page 7: Hdbaset Receiver
TL-TP70-HDIR User Manual 2.2 HDBaseT Receiver Front LINK HDCP Rear Figure 2- 2 Panel Description of RX No. Name Description HDBT Link status indicator, lights when the transmitter & receiver are linked and LINK communicating HDCP compliant indicator Ø Lights when input signal is HDCP encrypted HDCP Ø Blinks when the input signal is not HDCP encrypted Ø Turns off when there is no input Power Illuminates red when the unit is powered on Connect the included 5V IR Receiver (with carrier) to receive infrared signal, it will IR IN output at the RX IR OUT Connect the included 5V IR Emitter and attach to the IR window of the device you IR OUT wish to control. HDMI OUT Connect to an HDMI display Connect to the TP OUT socket on the HDBaseT Transmitter via shielded CAT5e/ TP IN CAT6 cable, supports bi-directional PoC. -
Page 8: System Connection
TL-TP70-HDIR User Manual 3. System Connection 3.1 Usage Precautions 1) System should be installed in a clean environment and has a proper temperature and humidity. 2) All of the power switches, plugs, sockets and power cords should be insulated for safety. 3) All devices should be connected before powering the extenders. 4) Use shielded straight-thru Cat5e/Cat6 cable with TIA/EIA T568B terminations. 3.2 System Diagram CAT5e/ 6 Cable HDMI Cable HDMI Cable HDTV Blu-ray DVD Figure 3- 1 System Connection 3.3 Connection Procedures Step1. Connect an HDMI source (such as a Blu-ray player) to the HDMI IN port of the transmitter with an HDMI cable. Step2. Connect the TP OUT port of the transmitter to TP IN port of the receiver via a shielded CAT5e/CAT6 cable. Step3. Connect an HDMI display (such as an HDTV) to the HDMI OUT port of the receiver with an HDMI cable. -
Page 9: Poc Solution
TL-TP70-HDIR User Manual Step4. When using the bi-directional IR control, do the following. a) Connect the included IR receiver to the IR IN port at either the transmitter or the receiver. b) Connect the included IR Emitter to the IR OUT port at the other end. Step5. Connect the included DC 12V power adaptor to the power port of the transmitter; the receiver will be energized synchronously. 3.4 PoC Solution The TL-TP70-HDIR boasts HDBT ports which support PoC. Connect the DC adapter to either the transmitter or the receiver, the other end will be energized simultaneously. (see in the following figure): CAT5e/ 6 Cable DC 12V Figure 3- 2 PoC Connection www.tlnetworx.com... -
Page 10: Arc Solution
TL-TP70-HDIR User Manual 3.5 ARC Solution The coax digital audio port and the HDMI ports support ARC (Audio Return Channel) which enables a display via a single audio/ HDMI cable to send (upstream) audio to amplifiers/ speakers, increasing user flexibility. The transmitter provides an ARC switch on the bottom panel to enable ARC mode selection. There are 2 modes in total, and connections will vary in different ARC modes to ensure normal ARC output. See the chart below: ARC Mode Description Connection Connect a source device (e.g.Blu-Ray DVD or AVR TX becomes the ARC (and CEC) host, that does not support allowing the ARC audio to be output ARC) to the HDMI input. -
Page 11: Application
TL-TP70-HDIR User Manual ARC Mode Description Connection Connect an ARC device ARC will be passed through the HDMI (e.g. Amplifier) to the TX input of the TX to an AVR that supports and an ARC display ARC. (Smart TV) to the RX. When the ARC switcher switched as “00”, connect the devices according to the following figure: CAT5e/ 6 Cable HDMI Cable HDMI 2 HDMI 1 with ARC) -
Page 12: Specification
TL-TP70-HDIR User Manual 4. Specification Model HDBaseT Transmitter HDBaseT Receiver Spec Input 1 IR, 1 TP Signal 1 HDMI, 1 IR 1 3.5mm mini jack 1 19-pin Type-A female HDMI Connector 1 3.5mm mini jack 1 RJ-45 Output 1 HDMI,1 IR Output 1 ARC, 1 IR, 1 TP 1 SPDIF 1 19-pin Type-A female HDMI Connector 1 3.5mm mini jack 1 3.5mm mini jack 1 RJ-45 General 800x600@60Hz~4K×2K@30Hz Resolution Range Transmission Mode HDBaseT 1080p 70m (TX and RX powered separately) -
Page 13: Supported Resolution
TL-TP70-HDIR User Manual 4.1 Supported Resolutions Aspect Ratio Resolution Refresh Rate 4096x2160 24/25/30Hz 4Kx 2K 3840x2160 24/25/30Hz 1920x1080 60Hz 1600x900 60Hz 16:9 1366x768 60Hz 1280x720 60Hz 1024x576 60Hz 1920x1200 60Hz 1680x1050 60Hz 16:10 1440x900 60Hz 1360x768 60Hz 1280x800 60Hz 1600x1200 60/65/70/75/85Hz 1400x1050 60Hz 1280x1024... -
Page 14: Panel Drawing
TL-TP70-HDIR User Manual 5. Panel Drawing HDBaseT Transmitter HDBaseT Receiver www.tlnetworx.com... - Page 15 l Ensure that the display device has been set to the correct input. l Ensure that the HDMI cables used for both the source/transmitter and the receiver/display are properly connected and are working. Test the HDMI cables directly from a source to display and ensure their operation. l Ensure that the Cat5e/Cat6 cable has not been damaged and that it has been terminated correctly with T568B on both ends. A temporary length of Cat5e/Cat6 can be used for testing to ensure that the devices are all compatible and working properly. l Ensure proper grounding of the power supply. l Known issues with HDMI 1.2 source devices: Older compatibility (HDMI 1.2) may result in HDBaseT transmission issues. Please contact Technical Support of your local distributor for a solution to these issues. l No output at the ARC port l In Bypass CEC mode: Loose or failed HDMI or ARC connection; Ensure HDMI IN port of TX is connected to an ARC device; There is connection at the ARC port of TX and the device is working normally. l In Force ARC mode: Loose or failed HDMI or ARC connection; There is connection at the ARC port of TX and the device is working normally. l Color loss or poor picture quality: l Ensure that the HDMI cables used for both the source and transmitter and the receiver and display are properly connected and are of good quality. Test the HDMI cables directly from a source to display and ensure their picture quality. l Ensure proper grounding of the power supply. l If the static becomes stronger or picture quality becomes worse when connecting the video connectors, this may be due to improper grounding. l Check the grounding and make sure all the components are properly grounded to a common ground. Improper grounding may cause damage to the receiver.
- Page 16 referenced in this user manual. 1) Product Limited Warranty: We warrant that our products will be free from defects in materials and workmanship for three years. Please see warranty page posted on www.tlnetworx.com for more info. 2) What the warranty does not cover: l Warranty expiration. l Factory applied serial number has been altered or removed from the product. l Damage, deterioration or malfunction caused by: l Normal wear and tear l Use of supplies or parts not meeting our specifications l No certificate or invoice as the proof of warranty. l The product model showed on the warranty card does not match with the model of the product for repairing or had been altered. l Damage caused by force majeure. l Non-authorized service l Other causes which does not relate to a product defect l Delivery, installation or labor charges for installation or setup of the product 3) Technical Support: Email or call our after-sales department, please prepare the following information about your cases. l Product version and name. l Detailed failure situations. l Date and place of purchase. Remarks: For any questions or problems, please try to get help from your local distributor.
