- Page 1 Model 7011 Installation Instructions www.LCDarms.com | 800.524.2744 © 2007 Innovative Office Products, Inc. P502986 REV B...
- Page 2 Model 7011 Parts List www.LCDarms.com | 800.524.2744 ITEM DESCRIPTION / PART NO. QUANTITY Tilter Adapter Bracket 104592 10-32 x 3/8" Philips Flat Head Screw 8 701164 Dog Washer 105189 10-32 x 3/8" FPhMS w/Lock Patch 1 705198 This product is protected by one or more of the following U.S. Patent Nos., and other United States and...
- Page 3 Model 7000 Installation Instructions www.LCDarms.com | 800.524.2744 B. or C. 800.524.2744 www.LCDarms.com © 2008 Innovative Office Products, Inc. P501288 REV C...
- Page 4 Model 7000 Parts List www.LCDarms.com | 800.524.2744 ITEM DESCRIPTION / PART NO. QUANTITY Sloped Tilter 405397 75mm VESA Adapter Plate 7VESA75 100mm VESA Adapter Plate 7VESA100 10-32 x 3/8" (9.525mm) Phillips Flat Head Screw (4-pack) 702281 M4-12 Phillips Pan Head Screw 702096 Dog Washer 105189...
- Page 5 Desk Clamp Thru-Desk 8111-cup, 8251-cup, 8318-cup 8111-thru, 8251-thru, 8318-thru Wall Mount Reverse Wall Mount 8111-wall, 8251-wall, 8318-wall Hardware NOT included. Hardware NOT included. Grommet Hole Side Bolt > 2.5" Hardware NOT included. © 2009 Innovative Office Products, Inc. P501296 REV B...
- Page 6 FLEX mount ™ Parts List www.LCDarms.com | 800.524.2744 ITEM DESCRIPTION / PART NO. QUANTITY Mount Column 401328 - Model 7000, Model 7045, Model 3500, Model 3545 8269 - Model 7500, iLift , ArcView (9177-2 & 9177-3) ™ ™ Base Plate 401417 - Model 7000, Model 7045, Model 3500, Model 3545 8321 - Model 7500, iLift , ArcView...
