  • Page 1 FPM-7620E Processing Module Guide FortiGate-7000E Series...
  • Page 2 FORTINET DOCUMENT LIBRARY https://docs.fortinet.com FORTINET VIDEO GUIDE https://video.fortinet.com FORTINET BLOG https://blog.fortinet.com CUSTOMER SERVICE & SUPPORT https://support.fortinet.com FORTINET TRAINING & CERTIFICATION PROGRAM https://www.fortinet.com/support-and-training/training.html NSE INSTITUTE https://training.fortinet.com FORTIGUARD CENTER https://fortiguard.com/ END USER LICENSE AGREEMENT https://www.fortinet.com/doc/legal/EULA.pdf FEEDBACK techdoc@fortinet.com Email: October 28, 2019 FPM-7620E Processing Module Guide...

  • Page 3: Table Of Contents

    Industry Canada Equipment Standard for Digital Equipment (ICES) – Canada European Conformity (CE) - EU Voluntary Control Council for Interference (VCCI) – Japan Bureau of Standards Metrology and Inspection (BSMI) – Taiwan China FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 4: Change Log

    Change log Date Change description October 28, 2019 Restructuring and bug fixing. FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 5: Fpm-7620E Processing Module

    The module lever mechanism helps reduce the engagement force required to insert or eject the module from the backplane connectors. FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 6: Power Sliders

    32 to 104°F (0 to 40°C) Storage Temperature -31 to 158°F (-35 to 70°C) Relative Humidity 10% to 90% (Non-condensing) Power consumption Max: 410W; Average: 320W Max Current Heat Dissipation 1395BTU/h Joules/h 1466KJ/h FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 7: Front Panel Leds

    NMI switch When working with Fortinet Support to troubleshoot problems with the FPM-7620E you can use the front panel non- maskable interrupt (NMI) switch to assist with troubleshooting. Pressing this switch causes the software to dump registers/backtraces to the console.

  • Page 8: Accelerated Ips, Ssl Vpn, And Ipsec Vpn (Cp9 Content Processors)

    Key Exchange Processor that supports high performance IKE and RSA computation Public key exponentiation engine with hardware CRT support Primary checking for RSA key generation Handshake accelerator with automatic key material generation True Random Number generator Elliptic Curve support for NSA "Suite B" FPM-7620E Processing Module Guide Fortinet Technologies Inc.
  • Page 9 Sub public key engine (PKCE) to support up to 4096 bit operation directly (4k for DH and 8k for RSA with CRT) DLP fingerprint support TTTD (Two-Thresholds-Two-Divisors) content chunking Two thresholds and two divisors are configurable FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 10: Hardware Installation

    When both power sliders are raised, the module cannot receive power. When the sliders are fully closed, the module can receive power if it is fully inserted into a chassis slot. FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 11: Inserting A Fpm-7620E Module Into A Chassis

    This section describes how to install a FPM-7620E module into a FortiGate-7000 series chassis slot 3 or up. The procedure includes photographs to illustrate the procedure steps. The photos were taken in one of Fortinet's hardware labs using a generic module and FortiGate-7000 chassis.
  • Page 12 Before sliding the final portion of the module into the chassis fully open both levers by pushing the power sliders up. Fully open both levers to avoid damaging the lever mechanism. Damaging the levers can prevent the module from connecting to power. Power slider Power slider Levers pop open FPM-7620E Processing Module Guide Fortinet Technologies Inc.
  • Page 13 The design of the levers leaves gaps to compensate for tolerances. So even when the levers are fully closed, the module may not be fully into position and in contact with the chassis backplane. Small gap between the module and the chassis when levers are closed. Rotate to close Levers closed FPM-7620E Processing Module Guide Fortinet Technologies Inc.
  • Page 14 Tighten by hand After tightening both secure screws, the module is fully engaged with the chassis. Fully tighten with a screwdriver FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 15: Shutting Down And Removing A Fpm-7620E Module From A Chassis

    This procedure describes how to shut down and remove a FPM-7620E module from FortiGate-7000 chassis. The procedure includes photographs to illustrate the procedure steps. The photos were taken in one of Fortinet's hardware labs using a generic module and FortiGate-7000 chassis.
  • Page 16 To shutdown the module, connect to the module GUI Shutdown from the administrator menu. Or, from the module CLI, enter the execute shutdown and select command. 2. Disconnect all cables from the module, including all network cables and USB cables or keys. FPM-7620E Processing Module Guide Fortinet Technologies Inc.
  • Page 17 Do not use a power screwdriver, because the high torque and speed can damage the chassis or screw thread. Use a Phillips screwdriver to loosen both screws. Fully loosen both screws by hand. FPM-7620E Processing Module Guide Fortinet Technologies Inc.
  • Page 18 4. Unlock the left and right levers by pushing the power sliders up until the levers pop open. Push the power sliders up to fully open both levers. If the chassis is powered on, this step turns off the module’s power. Power slider Power slider Levers pop open FPM-7620E Processing Module Guide Fortinet Technologies Inc.
  • Page 19 Module ejected Levers opened 6. Hold the levers to slide the module part way out of the chassis slot. Then grasp the module by the sides and carefully slide it out of the slot. FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 20: Troubleshooting

    To resolve the problem you can try removing and reinserting the FPM-7620E in the chassis slot. Reloading the firmware may also help. If this does not solve the problem there may have been a hardware failure or other problem. Contact Fortinet Technical Support for assistance.

  • Page 21: Cautions And Warnings

    être accordée aux connexions d'alimentation autres que les connexions directes au circuit de dérivation (par exemple de l'utilisation de bandes de puissance). Equipment must be used only with UL Listed ITE or Equivalent. L'équipement doit être utilisé uniquement avec UL ITE ou équivalent. FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 22: Safety

    Fiber optic transceiver must be rated 3.3V, 22mA max, Laser Class 1, UL certified component. Le transceiver optique doit avoir les valeurs nominales de 3.3 V, maximum 22 mA, Laser Class 1, homologué UL FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 23: Regulatory Notices

    European Conformity (CE) - EU This is a Class A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. FPM-7620E Processing Module Guide Fortinet Technologies Inc.

  • Page 24: Voluntary Control Council For Interference (Vcci) - Japan

    此 为 A级 产 品 ， 在 生 活 环 境 中 ， 该 产 品 可 能 会 造 成 无 线 电 干 扰 。 这 种 情 况 下 ， 可 能 需 要 用 户 对 其 采 取 切 实 可 行 的 措 施 。 FPM-7620E Processing Module Guide Fortinet Technologies Inc.
  • Page 25 Copyright© 2019 Fortinet, Inc. All rights reserved. Fortinet®, FortiGate®, FortiCare® and FortiGuard®, and certain other marks are registered trademarks of Fortinet, Inc., in the U.S. and other jurisdictions, and other Fortinet names herein may also be registered and/or common law trademarks of Fortinet. All other product or company names may be trademarks of their respective owners.
