Back View
O.
R.
Q.
N. Top Anchorage
(Tether) Strap Adjuster
O. Top Anchorage
(Tether) Strap
P. Top Anchorage
(Tether) Hook
Q. Vehicle Belt Attachment
Loops
12:02 PM Page 9
N.
S.
P.
Q.
R. Instructions
(in bottom of base)
S. Instructions Storage
(on select models, an
additional instruction
storage pocket is located
on backrest)
7
Q.
Y.
R.
U. U.
Z.
Bottom View
T.
U.
V.
T. LATCH Belt Adjuster
U. LATCH Storage
(under seat base)
V. Free End of LATCH Belt
Side View
Y.
N.
P.
Q.
W.
W. Free End of Harness
Strap
Y. Metal Harness Retainer
Z. Metal Buckle Retainer
