Crompton 264 Series Manual

Smart Tricolor or mono-color digital bargraph with a Universal Header Selectable

General Features

• A Tricolor or mono color (red or green), 0 segment high
brightness bargraph. Optional vertical or horizontal format.
• Red 4-digit LED display with range between –999 to
9999 (2000 counts). Optional green digital display.
• Front panel LED annunciators provide indication of set-
point status.
• Two 0 Amp Form C, and two 5 Amp Form A relays available.
• Auto-sensing AC/DC power supply. For voltages between
85-264 V AC / 110-370 V DC (Z) or 8-48 / 8-72 V AC / DC (Y).
• Optional isolated 6 bit analog output. User or factory
scalable to 4 to 20 mA, 0 to 20 mA or 0 to 0 V across
any desired digital span from ± one count to the full scale
range of – 999 to 9999 (2000 counts).
• Optional NEMA-4 front cover.
• Automatic averaging (6 sample moving average with eight
count replacement window to speed up display response).
• 24 V DC excitation is available to power external 4/20 mA
transmitters.
Software Features
• The bargraph can display,
full scale, any desired por-
tion of the digital reading.
• Bargraph center zero func-
tion.
• Four programmable set-
points.
• Setpoint  has delay-on-
make and delay-on-break
plus a special "pump on
pump off" mode that cre-
Code
Ordering
RELAYS
DTV: No Relays
DTT: Two 10A Form C Relays
DTF: Two 10A Form C Relays
and Two 5A Form A Relays
May 27, 2005 Crompton Bar Digital DS (NK2)
Input, an optional isolated analog output and up to four fully programmable set
points, for monitoring, measurement, and control applications.
ates a Hysteresis Band
between SP and SP2.
• Relay activation can be
selected to occur above
(hi) or below (Lo) each set-
point.
• Digital display blanking.
• Decimal point setting.
• Four-level brightness con-
trol of the bargraph and
digital display.
POWER SUPPLY UNIVERSAL PROCESS INPUT
A: 85 ~ 264V AC **: Custom Input
110 ~ 370V DC
1: 0 ~ 1mA
2: 4 ~ 20mA
B: 19 ~ 36V AC/DC
3: 0 ~ 1V
4: 1 ~ 5V
5: 0 ~ 5V
264 SerIeS
101 Segment Bargraphs
with Digital Display

Specifications

Input Specs: ..............Depends on range and function selected
A/D Converter:...........4 bit single slope
Accuracy: ...................±(0.05% of reading + 2 counts)
Temp. Coeff.: .............00 ppm/°C (Typical)
Warm up time: ...........2 minutes
Conversion Rate: ......0 conversions per second (Typical)
Digital Display: ..........4 digit 0.31" LED red (std), green (optn)
Bargraph Display: .....101 segment 4" red vertical (std),
Polarity: ......................Assumed positive. Displays – negative
Decimal Selection: ....Front panel button selectable, X•X•X•X•
Positive Overrange: ..Bargraph and top segments of digital
Negative Overrange: .First segment of bargraph and bottom
Relay Output: ............Two 5 Amp Form A relays and Two
Analog Output: ..........Isolated 6 bit user scalable mA or V
: (volts out) ............. 0-0 V DC @ 500 Ω or higher resistance
2: (mA out) ..............4-20 mA @ 0 to 500Ω max loop resistance
Power Supply: ...........AC/DC Auto sensing wide range supply
Y ..............................8-48 VAC / 8-72 VDC @ 2.5W max 4.2W
Z (std) .....................85-265 VAC / 95-370 VDC @ 2.5W max 4.2W
Operating Temp.: .......0 to 60°C
Storage Temp: ...........–20°C to 70°C
Relative Humidity: ....95% (non condensing)
Case Dimensions: .....3/32 DIN (Bezel 36Wx44Hmm)
Weight: .......................9.5 oz., 2 oz when packed
DISPLAY
VS: Vertical
HS: Horizontal
Crompton • www.crompton-instruments.com
of
Range –999 to 9999 counts.
green or tricolor (optn), horizontal (optn)
display flash.
segments of digital display flash.
0 Amp Form C relays.
Depth behind bezel 35 mm (5.32")
Plus 6 mm (0.63") for connectors
COLOR ANALOG OUTPUT
RD: Red Bargraph _: Custom Output
GN: Green Bargraph _: 0 ~ 10V
_: 4 ~ 20mA
YL: Yellow Bargraph
: Tricolor Bargraph _: 0 ~ 20mA
