Summary of Contents for Cata ASOMA 600
-
Page 2: Table Of Contents
Content 1…………………………………..………………………………Safety instructions 2…………………………………..………………………………Installation 3…………………………………..………………………………Start using your cooker hood 4…………………………………..………………………………Troubleshooting 5…………………………………..………………………………Maintenance and cleaning 6…………………………………..………………………………Environment protection... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS his manual explains the proper installation and use of your cooker hood, please read it carefully before using even if you are familiar with the product. The manual should be kept in a safe place for future reference. Never to do: Always to do: ●... - Page 4 Always to do: Always to do: ● ● lways put lids on pots and pans aution: The appliance and its when cooking on a gas cooker. accessible parts can become hot during operation. Be careful to avoid ● hen in extraction mode, air in the touching the heating elements.
- Page 5 INSTALLATION (VENT OUTSIDE) If you have an outlet to the outside, your cooker hood can be connected as below picture by means of an extraction duct (enamel, aluminum, flexible pipe or non- flammable material with an interior diameter of 150mm) Before installation, turn the unit off and unplug it from the outlet. 1.
- Page 6 Pic 4 4.Fix the pipe on the outlet, and use 4pcs screw ST4*14 to fix the PCB box, connect the power and finish the installation.(See pic 5) The distance between the edge of cooker hood and the hob should be at least 40mm.Refer to pic 6. Pic 5 Pic 6 ...
-
Page 7: Start Using Your Cooker Hood
Start Using Your Cooker Hood Slide control This control system consists of two parts, power panel and touch panel. Touch panel contains five function buttons (power, speed, light, timer, slide control) Timer Light Slide control Speed Power Functional Operation 1 Power on, the hood will standby with backlight, backlight will be extinguished after 5 seconds without any operation, for using the hood again, touch any key to wake up it’s standby motion. -
Page 8: Troubleshooting
touch slide button and slide to one light and it will be on, the light will be on in corresponding light intensity. It can also use the manual keys by touching the button to operate the hoods on one pilot light and it will be on in corresponding light intensity. -
Page 9: Maintenance And Cleaning
undertaking any of the above.Always disconnect the unit from the power source when opening the unit. MAINTENANCE AND CLEANING Caution: • Before maintenance or cleaning is carried out, the cooker hood should be disconnected from the main power supply. Ensure that the cooker hood is switched off at the wall socket and the plug removed. - Page 10 • Place the aluminium filter upside down. Then detach the charcoal filter. • Soak the aluminium filter into the solution of warm water and mild detergent for about 10 minutes. • Clean with a soft cloth/brush. Rinse thoroughly and dry well. •...
-
Page 11: Bulb Replacement
NOTE: Make sure the filter is securely locked. Otherwise, it would loosen and cause dangerous. When activated carbon filter attached, the suction power will be lowered. BULB REPLACEMENT The bulb must be replaced by the manufacturer, its Important : service agent or similarly qualified persons. -
Page 12: Environment Protection
ENVIRONMENTAL PROTECTION: This product is marked with the symbol on the selective sorting of waste electronic equipment. This means that this product must not be disposed of with household waste but must be supported by a system of selective collection in accordance with Directive 2012/19/EU.
