hp AlphaServer ES47/ES80/GS1280
I/O Drawer Upgrade
Order Number: EK-EGIOD-UP. B01
This manual is for field service engineers and self-maintenance customers
who are installing an I/O drawer upgrade into an hp AlphaServer ES47,
ES80, or GS1280 system.
Hewlett-Packard Company

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AlphaServer ES80 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HP AlphaServer ES80

Summary of Contents for HP AlphaServer ES80

  • Page 1 AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade Order Number: EK-EGIOD-UP. B01 This manual is for field service engineers and self-maintenance customers who are installing an I/O drawer upgrade into an hp AlphaServer ES47, ES80, or GS1280 system. Hewlett-Packard Company...
  • Page 2 HP shall not be liable for technical or editorial errors or omissions contained herein. The information in this document is provided “as is” without warranty of any kind and is subject to change without notice.
  • Page 3 Japanese Notice Canadian Notice This Class A digital apparatus meets all requirements of the Canadian Interference-Causing Equipment Regulations. Avis Canadien Cet appareil numérique de la classe A respecte toutes les exigences du Règlement sur le matériel brouilleur du Canada. European Union Notice Products with the CE Marking comply with both the EMC Directive (89/336/EEC) and the Low Voltage Directive (73/23/EEC) issued by the Commission of the European Community.

  • Page 5: Table Of Contents

    Contents Preface Intended Audience ......................... ix Document Structure ....................... ix Information on the Internet ..................... x Chapter 1 Overview System Components ....................1-2 Upgrade Kit ......................1-4 Upgrade Steps......................1-5 Chapter 2 Prepare the System Verify I/O Drawer Location .................. 2-2 Check Upgrade Components .................
  • Page 6 Example 4–2 Run Show Cable ................... 4-4 Example 4–3 Run Connect ....................4-6 Table of Figures Figure 1–1 Example hp AlphaServer System (ES80 Model 8).......... 1-2 Figure 2–1 Turn Off Power....................2-5 Figure 2–2 Remove Side Panel (Example) ................. 2-7 Figure 3–1 Installing the Inner Slides .................
  • Page 7 Figure 3–21 Restore Power....................3-32 Table of Tables Table 1 hp AlphaServer ES47/ES80/GS1280 Documentation .......... x Table 1–1 I/O Drawers Supported by Model ..............1-3 Table 1–2 I/O Upgrade Kit Contents ................. 1-4 Table 1–3 I/O Drawer Upgrade Steps ................. 1-5 Table 2–1 Items Needed for I/O Upgrade................
  • Page 8 viii...

  • Page 9: Preface

    Preface Intended Audience This manual is for service providers of hp AlphaServer ES47/ES80/GS1280s who are upgrading their system(s) with one or more I/O drawers. Document Structure This manual uses a structured documentation design. Topics are organized into small sections, usually consisting of two facing pages. Most topics begin with an abstract that provides an overview of the section, followed by an illustration or example.

  • Page 10: Information On The Internet

    This site is updated as new revisions and manuals are produced. Table 1 lists some of the available documents. Firmware downloads are available at: ftp://ftp.digital.com/pub/Digital/Alpha/firmware/index.html http://ftp.digital.com/pub/Digital/Alpha/firmware/index.html Table 1 hp AlphaServer ES47/ES80/GS1280 Documentation Title Pages Size HTML hp AlphaServer ES47/ES80/GS1280 Site Preparation 1.02 MB...

  • Page 11: Chapter 1 Overview

    Chapter 1 Overview The hp AlphaServer ES47/ES80/GS1280 family supports four types of optional I/O drawers: 1. I/O Master Drawer, containing: • 10 PCI/PCI-X slots • One AGP slot • An N+1 redundant power system • A CD-RW drive • Two Ultra3 SCSI hot-plug disk drive bays (the disk drives must be ordered separately).

  • Page 12: System Components

    System Components The hp AlphaServer ES47/ES80/GS1280 family supports from one to sixteen I/O drawers or up to two high-performance I/O drawers, the maximum depending on the type of system. Figure 1–1 Example hp AlphaServer System (ES80 Model 8) 1-2 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 13: Table 1-1 I/O Drawers Supported By Model

    The maximum number and type of I/O drawers you can install in your hp AlphaServer system depends upon the type of system you have, as shown in Table1–1. Table 1–1 I/O Drawers Supported by Model hp AlphaServer I/O Drawer High-performance...

  • Page 14: Upgrade Kit

    Screws, Phillips pan head, SEMS, M6 x 18mm 90-11476-01 Cagenuts 90-40347-02 Screws, machine, M4 x 6mm long (truss head) 70-41070-01 Cable guides 90-11593-02 Grommet strip 37-01729-02 Packaging material 70-41162-01 Cable support bracket 74-62871-01 Cable support base mounting bracket 1-4 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 15: Upgrade Steps

    Upgrade Steps Here are the basic steps you will perform when installing an upgrade. NOTE: You must update your system to the latest firmware levels. The I/O drawers you are installing have factory-installed versions of the most recent firmware. You cannot successfully upgrade the hardware without upgrading the firmware on your original system.
  • Page 16 1-6 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 17: Chapter 2 Prepare The System

    Chapter 2 Prepare the system You have opened your upgrade kit and checked the contents (Chapter 1). An important initial step is to make sure you have an appropriate 4U cabinet space for the I/O drawer upgrade. Next, make sure you have all the hardware components to proceed with the upgrade.

  • Page 18: Verify I/O Drawer Location

    Verify I/O Drawer Location Use the appropriate QuickSpecs for your hp AlphaServer system to verify that you have an appropriate available 4U space into which to install your I/O upgrade drawer. Make sure you have sufficient expansion space in your system to accommodate the I/O drawer upgrade.

  • Page 19: Check Upgrade Components

    Check Upgrade Components Before you begin systematic shutdown of your system, double-check your upgrade kit contents to be certain you have all necessary components. Assemble your tools. Clear a space around the side and rear of the cabinet into which you are going to install the I/O drawer. Table 2–1 Items Needed for I/O Upgrade Part Number Description...

  • Page 20: Check I/O Cable Length

    CPU drawer. Verify that you have sufficient cables of the correct length. Table 2–2 summarizes the I/O cables that are used in different hp AlphaServer systems. The I/O cable(s) you need for your upgrade depends on the distance between the I/O drawer and its corresponding CPU drawer.

  • Page 21: Shut Down System Power

    Shut Down System Power Perform your regular system maintenance. Back up all important data, systematically shut down your applications. And perform an orderly shutdown of the operating system. Figure 2–1 Turn Off Power Table 2–3 OCP LED Table Amber Green •...
  • Page 22 Execute the power off command using the OCP pushbuttons on the drawer that contains the target CPU. 2. Wait for the orderly shutdown to complete. 3. Unplug the CPU drawer from its power source. hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 23: Remove The Side Panel

    Remove the Side Panel Remove the side panel of the cabinet into which you are going to install the I/O drawer. You need access to the side rails of this cabinet to properly ground your I/O drawer. Figure 2–2 Remove Side Panel (Example) d.
  • Page 24 AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 25: Chapter 3 Install And Cable The I/O Drawer

    Chapter 3 Install and cable the I/O drawer Next we will install the I/O drawer. We will then connect and route one or more I/O cables, used to connect the I/O risers in the I/O drawer to the corresponding CPU drawer(s). Then, we will connect and route the Ethernet, ground, and power cables.

  • Page 26: Install The Inner Slides

    Install the Inner Slides Attach the inner halves of the slides to the I/O drawer. Figure 3–1 Installing the Inner Slides hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 27 Refer to Figure 3–1 and install the inner halves of the slides on the I/O drawer as follows: 1. Separate the slides so that their inner and outer halves are completely apart. 2. On each side of the I/O drawer, use three M4 truss head machine screws to attach the inner half of the slide to the drawer.

  • Page 28: Determine Hole Locations For Installation

    Determine the hole locations for mounting the outer slides, cable retainer, and cable guides. The hole locations vary according to the type of cabinet into which you are mounting the I/O drawer. Figure 3–2 Hole Locations for GS1280 Systems (Front View) hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 29: Figure 3-3 Hole Locations For Es47 And Es80 Systems

    Figure 3–3 Hole Locations for ES47 and ES80 Systems Refer to Figures 3–2 and 3–3 to determine the hole locations and numbers for the outer slides (rails) and the cable retainer. Cabling...

  • Page 30: Loosely Attach Outer Slides

    Loosely Attach Outer Slides Loosely attach the outer halves of the slides to the cabinet rails. Figure 3–4 Installing the Outer Slides hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 31 Refer to Figure 3–4 and install the outer halves of the slides on the cabinet rails as follows: 1. Install cagenuts (8) on the front and rear vertical rails. Be sure they are installed in the correct holes as specified in Section 3.2. 2.

  • Page 32: Attach Cable Retainer And Grommet

    Attach Cable Retainer and Grommet Then, attach a cable retainer and grommet to the front right (as viewed from the front) cabinet vertical rail. Figure 3–5 Installing the Cable Retainer hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 33 Refer to Figure 3–5 and install the cable retainer and grommet on the front right (as viewed from the front) cabinet rail as follows: 1. Install cagenuts (2) on the front right vertical rails (as viewed from the front), making sure to use the correct hole numbers as specified in Section 3.2. 2.

  • Page 34: Install The I/O Drawer

    Install the I/O Drawer Tighten one outer slide half, slide the I/O drawer into the cabinet, and then tighten the other outer slide half. Figure 3–6 Installing the I/O Drawer 3-10 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 35 CAUTION: Two people are required to lift and install the I/O drawer in the cabinet. Estimated weight of the drawer is 143 kg (65 lb). 1. Align one outer slide half such that the slots for the screws in the slide half are centered horizontally and vertically with respect to the screws.

  • Page 36: Install Cable Support Rack And Drawer Latches

    Install Cable Support Rack and Drawer Latches Install the I/O cable support rack and drawer latches on the rear of the I/O drawer. Figure 3–7 Installing Cable Support Rack and Drawer Latches (Rear View) 3-12 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 37 Refer to Figure 3–7 and install the cable support rack and drawer latches as follows: 1. Slide the I/O drawer out slightly so you can easily access the back of the drawer. 2. Insert the tab at the bottom of the cable support rack into the hole at the rear of the I/O drawer 3.

  • Page 38: Attach Cable Guides

    Attach two cable guides to the rear cabinet vertical rails. The hole locations for mounting this hardware depends on the type of cabinet into which you are installing the I/O drawer. Figure 3–8 Attaching Cable Guides (Rear View) 3-14 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 39 Refer to Figure 3–8 and install the cable guides on the rear cabinet rails as follows: 1. For each bracket, install a cagenut on the rear vertical rails, making sure to use the correct holes as specified in Section 3.2. 2.

  • Page 40: Attach Cable Support Bracket On Rear Door

    For 34U and 41U cabinets, install a cable support bracket inside the cabinet back door. For 42U cabinets, skip this step; installation of a rear door cable support bracket is not necessary. Figure 3–9 Attaching Cable Support Bracket on Rear Door 3-16 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 41 For 34U and 41U cabinets, refer to Figure 3–9 and install a cable support bracket on the inside of the rear door as follows: 1. Place the cable support bracket over any of the five horizontal welded supports on the inside back door. 2.

  • Page 42: Identify I/O Connector On Cpu Drawer

    Use the tables in Figure 3–10 to identify the cabinet, drawer, and slot number of the port to which your I/O drawer will connect. Figure 3–10 CPU Drawer I/O Cable Connections for GS1280 3-18 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 43 Figure 3–10 CPU Drawer I/O Cable Connections for GS1280 (Continued) For GS1280 systems, you can use the tables shown in Figure 3-10 to determine which I/O port (connector) on the CPU drawer connects to the I/O riser (IO7) in the drawer you are installing.

  • Page 44: 3.10 Connect I/O Cable(S) To Cpu Drawer

    Figure 3–11 I/O Cable Connections to CPU Drawer for GS1280 Figure 3–12 I/O Cable Connections to CPU Drawer for ES47 or ES80 3-20 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 45 Connect each I/O cable to a CPU drawer as follows: From the rear of the cabinet, slide out the appropriate CPU drawer. • Remove the cable cover from the appropriate connector. • Attach one end of the I/O cable to the connector. •...

  • Page 46: Route The I/O Cable(S)

    3.11 Route the I/O Cable(s) Route each I/O cable from the CPU drawer to the I/O drawer. Use cable channels and supports where appropriate. Figure 3–13 I/O Cable Routing 3-22 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 47 CPU drawer 3, slot 5 to I/O drawer 0 (the eighth I/O drawer in the system) in the expansion cabinet. The specific route of the cable depends on the type of hp AlphaServer configuration you have. Cabling...

  • Page 48: 3.12 Connect I/O Cable(S) To I/O Drawer

    Connect each I/O cable to an I/O riser in the drawer and drape the cable appropriately around the guides. Figure 3–14 I/O Cable Draping (GS1280) Figure 3–15 I/O Cable Draping (ES47 and ES80) 3-24 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 49 Connect each I/O cable to the I/O drawer as follows: 1. From the rear of the cabinet, slide out the I/O drawer. 2. Connect the I/O cable to the I/O riser connector on the back of the drawer. 3. Drape the cables on the I/O drawer guides as shown in Figures 3–14 and 3–15. Cabling 3-25...

  • Page 50: 3.13 Connect Ethernet, Ground, And Power Cables

    3.13 Connect Ethernet, Ground, and Power Cables After installing the I/O cable(s), plug the server management Ethernet cable into the server management HUB. Then install the power cables to the PDU. Figure 3–16 Ethernet, Ground, and Power Cables 3-26 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 51: Figure 3-17 Pdu Connections

    Figure 3–17 PDU Connections Note: Create a proper service loop. Make sure you leave enough Ethernet and power cable loose to allow full extension when the drawer needs to be serviced. 1. Plug the Ethernet cable into the I/O drawer and route the cable up the right vertical rail to the HUB.

  • Page 52: 3.14 Replace The Side Panel

    3.14 Replace the Side Panel Working from the side of the system, return the side panel to the cabinet. Figure 3-18 shows an example system. Figure 3–18 Replacing the Side Panel (Example) 3-28 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 53 Hook the top of the side panel onto the cabinet. Working top down, press the side panel onto the cabinet frame. Push the bottom in tightly. 1. Insert and tighten the screws at the bottom of the panel (front and rear). For 42U cabinets, use your system key to secure panels to rails.

  • Page 54: 3.15 Set The Drawer Id

    If, for example, you have no PCI in the position associated with ID-6, you do not assign that ID to the drawer above it. The drawer above retains ID-7 to indicate its physical position in the cabinet, and the drawer below is ID-5 3-30 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 55: Figure 3-20 Id Numbers (Example For Es80 System)

    Table 3–1 Drawer IDs (Example for ES80 System) Position Set drawer ID Model PCI drawer, 5 from bottom PCI drawer, 6 from bottom PCI drawer, 7 from bottom PCI drawer, 8 from bottom Figure 3–20 ID Numbers (Example for ES80 System) Cabling 3-31...

  • Page 56: 3.16 Restore Power

    Vaux on, bulk power off, attention error inside the box Vaux on, bulk power on, no errors Vaux on, bulk power on, attention error inside the box • The top LED is amber and the bottom LED is green. 3-32 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 57: Chapter 4 Configure And Troubleshoot

    Chapter 4 Configure and Troubleshoot This chapter covers power-up following the hardware upgrade, and configuration of the newly installed elements into the system using the firmware. Some troubleshooting is also included. Examples show sample console displays for a GS1280 system. Two conventions are used: 1.

  • Page 58: Notify Server Management Of New Members

    [2003/07/16 07:28:51] ~REC-W-(trecTask) Server management group is transitioning. ~GRP-W-(grp_Create) Joined Group ID: 100000a.8 ~GRP-W-(grp_Monitor) Leaving Group ID: 100000a.8 ~GRP-W-(grp_Monitor) Joined Group ID: 100010a.9 1 -dr ~GRP-W-(grp_Probe) MBM/PBM cab:01 drw:6 is not in the member list. hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 59 ~GRP-W-(grp_Probe) Use Set Membership -add -ca 1 -dr 6 PBM 6 pbm ~GRP-E-(grp_IAmAlive) MISSING NEIGHBOR timeout from Cab: 1, Drawer: 7 Cab Drw Module MicroID IP Address In Group 100000a 10.0.0.1 TRUE 100010a 10.1.0.1 TRUE 2fe0a 10.254.2.0 TRUE 103fe0a 10.254.3.1 TRUE 104fe0a 10.254.4.1...

  • Page 60: Run Show Cable And Verify Configuration

    ------- ------- ------- ------- MBM> MBM> p on [2003/07/16 07:32:37] ~PCO-I-(pco_01) Preparing to power on partition. HP: Default_HP [2003/07/16 07:32:47] ~PCO-I-(pco_01) << ------------ lines deleted ------------- >> AlphaServer Console V6.5-8, built on May 9 2003 at 10:10:56 P00>>> P00>>>sho config...
  • Page 61 + USB usbd + CMD 649 PCI-IDE + Adaptec AIC-7892 << ------------ lines deleted ------------- >> Intel 21154-*E + USB usbe + USB usbf + USB usbg + USB usbh + CMD 649 PCI-IDE + Adaptec AIC-7892 Adaptec AIC-7899 + Adaptec AIC-7899 DEGPA-TA Intel 21154-*E + DE602-B*...

  • Page 62: Connect To Partition

    1. Enter the command conn or connect 2. Connects to partition using the CPU associated with the I/O drawer you just installed. 3. Check your I/O count here. 4. Prompt appears. Connection is complete. hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 63: Troubleshooting During Console Power-Up

    Troubleshooting During Console Power-up If your server management keeps looping on trying to form the group, then you need to check your NAT box carrier lights for port connections. Next check all drawers within the cabinet (I/O and CPU drawers) to be certain they have unique identifiers.

  • Page 64: Troubleshooting Power During Power-Up

    Poor connections along the path from the No messages on power up. console, wherever it is, to the internal LAN. the console Router broken No messages on the console Vaux problem See Vaux problems hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 65: Table 4-3 Troubleshoot With The I/O Drawer Ocp

    Table 4–3 Troubleshoot with the I/O Drawer OCP Symptom Possible Cause Indicators System does not power up. I/O drawer OCP 48V problem OCP LEDs off Table 4–4 Troubleshoot 48V Issues Symptom Possible Cause Indicators System or part of Any Vaux problem will cause 48V problems See the Vaux, the system does LAN and OCP...
  • Page 66 4-10 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 67: Chapter 5 Verify With Q-Vet

    Chapter 5 Verifying with Q-Vet Use Q-Vet to verify your newly upgraded system. The following topics are covered here: • Run Q-Vet • Installing Q-VET • Running Q-VET • Reviewing Q-VET Results • De-Installing Q-Vet Verify with Q-Vet 5-1...

  • Page 68: Run Q-Vet

    Non-IVP Q-Vet scripts verify disk operation for some drives with write-enabled techniques. These are intended for engineering and manufacturing test only. Q-Vet must be de-installed upon completion of system verification. hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 69: Swap Or Pagefile Space

    5.1.1 Swap or Pagefile Space The system must have adequate swap space (on Tru64 UNIX) or pagefile space (on OpenVMS) for proper Q-Vet operation. You can set this up either before or after Q-Vet installation. If during initialization Q-Vet determines that the system does not have enough swap/pagefile space, it will display a message indicating the minimum amount needed.

  • Page 70: Installing Q-Vet

    You can also delete the kit tar file, QVET_Vxxx.tar. 9. You must reboot the system before starting Q-Vet. 10. On reboot you can start Q-Vet GUI via vet& or you can run non GUI (command line) via vet -nw. hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 71: Openvms

    5.2.2 OpenVMS 1. Delete any QVETAXPxxx.A or QVETAXPxxx.EXE file from the current directory. 2. Copy the self-extracting kit image file (QVETAXPxxx.EXE) to the current directory. 3. We recommend but do not required, that you purge the system disk before installing Q-Vet. This will free up space that may be needed for pagefile expansion during the AUTOGEN phase.

  • Page 72: Running Q-Vet

    Long IVP (the IVP tests will then load into the Q-Vet process window). Click the Start All button to begin IVP testing. $ vet /int=char Command-Line Q-Vet_setup> execute ivp.vms Interface Q-Vet_setup> start Note that commands are case sensitive. hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
  • Page 73 NOTE: A short IVP script is provided for a simple verification of device setup. To run the short script, select the appropriate file, .Ivp_short.scp or ivp_short.vms from the GUI IVP menu. This script will run for 15 minutes and then terminate with a summary log. The short script may be run as a preliminary to but not in place of the long IVP script, which is the full IVP test.

  • Page 74: Reviewing Q-Vet Results

    Run Compaq Analyze to review test results. The IVP scripts do not translate events unless they are Q-Vet detected errors. The testing times (for use with Compaq Analyze) are printed to the Q-Vet run window and are available in the summary log. hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...

  • Page 75: De-Installing Q-Vet

    De-Installing Q-Vet De-installation of Q-Vet differs between operating systems. You must de-install Q-Vet from each partition in the system. Failure to do so may result in the loss of customer data at a later date if Q-Vet is misused. Follow the instructions listed under your operating system to de-install Q-Vet from a partition.
  • Page 76 5-10 hp AlphaServer ES47/ES80/GS1280 I/O Drawer Upgrade...
