- Page 1 X 400 | X 500 Quick User Guide rapidcount X 400 rapidcount X 500...
-
Page 2: Safety Precautions
To get the most out of your ratiotec rapidcount X 400/X 500 bill counter, we advise you read the entire quick user guide for best use and maintenance instructions. -
Page 3: Front View
[ EN] Front View Bill guides 2. Display Control panel 4. Stacker Hopper 6. Reject pocket (X 500 only) Carrying handles 8. Power switch USB port Rear View Feed gap adjustment screw 2. Top panel release handle Rear panel (X 500 only) 4. -
Page 4: Getting Started
[EN] Getting Started Place the machine on a flat and stable surface 2. Remove the protective film from the touchscreen Connect and adjust the bill guides 4. Connect the power cable to the machine, and then a grounded outlet Flip the power switch to the on position 6. -
Page 5: Control Panel
[ EN] Control Panel Press to change the currency setting. Select your currency from the options displayed on the touchscreen. Adjust the bill guides accordingly. Press to change the operational mode. Select your counting mode from the options displayed on the touch- screen. -
Page 6: Setting Date/Time
Control Panel (continued) Press and hold for three seconds to clear the current count session. Press to start or stop the count. (X 500 only): Press and hold 0 for three seconds to activate Face sorting. Run a stack of bills though the machine while Face sorting is activated, and the stack will be sorted into two stacks, one face up and one face down, which can be combined to all face the same way. -
Page 7: Error Messages
Error Messages Error Message Solution Sensor Start Error with the start sensor. Remove any bills from the hopper and clean the start sensor. Make sure there are no bills in the hopper when powering the machine on. Sensor Stacker Error with the stacker sensor. Remove any bills from the stacker and clean the stacker sensor. - Page 8 X 400 | X 500 Quick User Guide ratiotec GmbH & Co. KG Max-Keith-Str. 66 | 45136 Essen T: +49(0)201 / 361 49 – 0 F: +49(0)201 / 361 49 – 26 E-Mail: info@ratio-tec.de Internet: www.ratio-tec.com...
