Aiphone JSS-1A Operation Manual

Hands-free color video intercom set (js-1md master monitor station, js-da video door station, and power supply), sub monitor station
Hide thumbs Also See for JSS-1A:

Advertisement

Quick Links

Download this manual
HANDS-FREE COLOR VIDEO INTERCOM SET
(JS-1MD MASTER MONITOR STATION,
JS-DA VIDEO DOOR STATION, and power supply)
• Read this "Operation Manual" prior to usage to ensure safe and correct operation. Keep this in a
safe place for future reference.
• The illustrations used in this manual may differ from the actual ones.
JSS-1A
JS-1HD
SUB MONITOR STATION
OPERATION MANUAL
JS-DA
JS-DA
JS-1MD/JS-1HD
* The illsutration is JS-1MD.

Advertisement

loading

Related Manuals for Aiphone JSS-1A

Summary of Contents for Aiphone JSS-1A

  • Page 1 JSS-1A HANDS-FREE COLOR VIDEO INTERCOM SET (JS-1MD MASTER MONITOR STATION, JS-DA VIDEO DOOR STATION, and power supply) JS-1HD SUB MONITOR STATION OPERATION MANUAL JS-DA JS-DA JS-1MD/JS-1HD * The illsutration is JS-1MD. • Read this "Operation Manual" prior to usage to ensure safe and correct operation. Keep this in a safe place for future reference.
  • Page 2 Failure to do so may result in fire or switch on the side of the station. electrical shock. This may result in fire or electrical shock. ■ Use■the■Aiphone■power■supply■specific■for■ ■ use■with■the■system. ■ Keep■the■station■away■from■liquid. ■ This may result in fire or malfunction.
  • Page 3 ● Aiphone is not to be held responsible for any and all damages resulting from malfunctions, defects, or misuse of this product. ● This product cannot be used during power outages.

  • Page 4: Part Names And Functions

    PREPARATION Part names and functions Monitor■station■JS-1MD/JS-1HD * The illustration is JS-1MD. Power switch Color LCD screen Microphone During calling, communication, or [ Left side] Do not cover the microphone monitoring, the video of the door with a sticker or adhesive station is displayed.
  • Page 5 PREPARATION Video■door■station■(JS-DA) Camera-angle adjustment lever Camera The camera-angle adjustment lever is back of the door station. Refer to the Installation manual for details. [ Back ] Front panel Microphone Location LED (red) Camera-angle adjustment lever Lights red to indicate the Call button in dark places.

  • Page 6: Receiving A Call

    USING THE STATION Receiving a call Video door station Monitor station (Hands-free talk) Ding-dong, When the video is displayed after a call is placed... ding-dong. Press [ ] button once. Ding-dong, JS-DA ding-dong. JS-DA When you press Beep the Call button at night, the White light LED lights up.
  • Page 7 USING THE STATION Adjust the incoming ringtone volume Adjust the ringtone volume by pressing the “Volume 【Call duration】 control” button during standby. ・The screen turns off after approx. 45 seconds, if Volume is adjustable with "Low", "Medium", "High", and "Mute". * The factory default is "Medium".
  • Page 8 USING THE STATION Using the Press-to-Talk mode Press-to-Talk is useful when the ambient noise is loud enough to interrupt audio. Press and hold [ ] button (more than 2 seconds) until the beep sounds. Beep Hold [ ] button to speak and then release it to listen.
  • Page 9 USING THE STATION Monitoring the door station Video door station video and audio can be monitored. Audio of the monitor station cannot be heard from the video door station until pressing [ button. Screen brightness is adjustable during monitoring. (Page 7) Press [ ] button once.

  • Page 10: Troubleshooting

    OTHERS Troubleshooting Problem Cause Solution Page ・ The screen is black. ・ The color LCD screen ・ Press [ ] button to display at is off in standby mode. the door station. ・ Nothing is displayed ・ The power switch on ・...

  • Page 11: Maintenance Specifications

    OHTERS Maintenance/Specifications Cleaning Clean the station with a soft cloth dampened with a neutral household cleanser. Do not use any abrasive cleaner or cloth. CAUTION:■ Do■not■use■chemicals■such■as■thinner■or■benzine.■In■addition,■do■not■use■a■scrub■brush,■ sandpaper,■etc.■Use■of■such■substances■will■damage■or■discolor■the■station■surface. Specifications JS-1MD■(Master■monitor■station)■/■JS-1HD■(Sub■monitor■station) Power supply 24 V DC JS-1MD: (MAX) Approx. 225 mA, Current consumption JS-1HD: (MAX) Approx.
  • Page 12 Regulations Aiphone warrants its products to be free from defects of material and workmanship under normal use and service for a period of 2 years after delivery to the ultimate user and will repair free of charge or replace at no charge, should it become defective upon This device complies with part 15 of the FCC Rules.
