Chamberlain EL1SS Resident Manual

EL1SS
How a Visitor Contacts the Resident:
When a visitor presses the "CALL" button, the system rings your telephone.
1 2 3
4 5 6
7 8 9
* 0 #
Lyl
War
1 2 3
4 5 6
7 8 9
* 0 #
Visitor presses call button to
contact resident.
When You Answer the Visitor's Call:
When the home phone receives a call from the EL1SS,
answer the call to initiate the audio and to speak to
visitor. To deny the caller access to the property, hang
up. To extend the talk time press 0 or continue talking.
NOTE: The home phone is a phone wired directly to the
EL1SS system. To use a cell phone, see call forwarding
instructions on next page (not available in intercom
mode).
CALL WAITING (Single Family Residence ONLY):
Press "Flash" once to answer guest, press again to
return to outside call on telco line, if *9 or *5 is not
pressed. If *9 (relay 1) or *5 (relay 2) is pressed, the
EL1SS will automatically return to the telco line.
GRANTING ACCESS:
Press * 9 to grant access through the door or gate
connected to Relay 1. The call will end.
or
Press * 5 to grant access through the door or gate
connected to Relay 2. The call will end.
Using Entry Codes:
NOTE: Use the "*" key to cancel an entry. The system will generate a dual tone beep for a valid entry code
or three short low tone beeps for an error or invalid entry code.
Telephone Entry System
Resident Guide
Resident answers the call. Resident grants access
*
by pressing
hanging up.
An Entry Code allows access by entering a numeric code on the EL1SS keypad.
Enter your assigned Entry Code for access (see chart below). If you make an error
while entering your code, press "*" to cancel.
Standard 4-Digit Code
Special Use 5-Digit Code (Relay 1) Entry Code (4 digits) + 1 Activates relay 1
Special Use 5-Digit Code (Relay 2) Entry Code (4 digits) + 2 Activates relay 2
9 or *5 or denies access by simply
Extend talk
time (also
activate
audio for call
forwarding
calls)
Entry Code (4 digits)
Visitor gains entry
12:00
AM
Hang up to
Dec. 31
deny access
MENU REDIAL
to the visitor
TALK OFF
Toggle between visitor
FLASH
and another phone call
1 2 3
&') ABC DEF
Activate all entry
4 5 6
GHI JKL MON
devices connected
7 8 9
PQRS TUV WXYZ
To Relay 2
0 #
OPER
Activate all entry
devices connected
To Relay 1
Activates the pre-assigned
relay when the code was
created
