Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
hardware which may have come loose inside the carton during shipment. Identify and count all hardware
and compare with the hardware list below.
When placing furniture on non-carpeted flooring, HMI recommends the use of floor protection such as
an area rug or furniture pads. Area rugs and padding not included with purchase.
No.
1
2
3
No.
A
JCBC Screw M6 x 70mm
B
JCBB Screw M8 x 70mm
C
Spring Washer M8 x 13mm Ø
D
Flat Washer M8 x 22mm Ø
E
Metal Plate 50 x 2mm
F
Metal Stretcher 1214 x 32mm Ø
G
Allen Key M4 x 65mm
H
Allen Key M5 x 65mm
Made In Malaysia
L I V I N G S P A C E S
ASSEMBLY INSTRUCTIONS
ITEM - 305-P139240 & 305-P139241
Dining Table
PARTS LIST
Description
Table Top
Table Leg
Top Leaf
HARDWARE LIST
Description
Sketch
Sketch
Quantity
1 pc
2 pcs
1 pc
Quantity
2 pcs
8 pcs
8 pcs
8 pcs
2 pcs
1 pc
1 pc
1 pc
Page 1 of 3
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Living Spaces 305-P139240
Summary of Contents for Living Spaces 305-P139240
- Page 1 L I V I N G S P A C E S ASSEMBLY INSTRUCTIONS ITEM - 305-P139240 & 305-P139241 Dining Table Thank you for purchasing this quality product. Be sure to check all packing material carefully for small hardware which may have come loose inside the carton during shipment. Identify and count all hardware and compare with the hardware list below.
- Page 2 L I V I N G S P A C E S STEP 1 - Place Table Top (1) on a clean flat surface attach with Table Leg (2). Do not fully tighten at this moment. STEP 2 - Attach Table leg (2) to Metal Stretcher (F), Tighten all the bolts and take care do not over tighten.
- Page 3 L I V I N G S P A C E S COMPLETE Made In Malaysia Page 3 of 3...
