RouterBOARD 9 51-­‐2n
Quick S etup G uide a nd W arranty I nformation
Connecting
1. Connect y our W AN c able t o p ort 1 , a nd L AN P Cs t o p orts 2 -­‐5
2. Set L AN c omputer I P c onfiguration t o a utomatic ( DHCP)
3. Default I P a ddress f rom L AN/WLAN i s 1 92.168.88.1, o pen t his
address i n y our w eb b rowser t o s tart c onfiguration. T he u sername i s
admin a nd t here i s n o p assword ( Alternatives a re S SH, T elnet o r
Winbox t ool)
4. Wireless A P m ode i s e nabled b y d efault, y ou c an c onnect t o t he S SID
"MikroTik". L og i nto y our r outer a nd c onfigure a W PA p assword t o
secure y our n etwork
Powering
The d evice a ccepts p owering f rom t he p ower j ack o r f rom t he f irst e thernet p ort ( Passive P oE):
DC p ower j ack ( 5.5mm o utside a nd 2 mm i nside d iameter, f emale, p in p ositive p lug) a ccepts 8 -­‐30V D C
•
The f irst e thernet p ort a ccepts p assive P ower o ver E thernet a ccepts 8 -­‐30V D C
•
Under m aximum l oad, t he p ower c onsumption o f t his d evice i s 3 W
Booting p rocess
Initial c onnection h as t o b e d one v ia t he E thernet c able. O pen 1 92.168.88.1 i n y our w eb b rowser, a nd c hoose
"Webfig" f or b rowser b ased c onfiguration o r " Winbox" f or a W indows u tility w ith t he s ame f unctions. U sername
is a dmin a nd t here i s n o p assword. I n c ase I P c onnection i s n ot a vailable, W inbox c an b e u sed t o c onnect t o t he
MAC a ddress o f t he d evice. M ore i nformation h ere: h ttp://wiki.mikrotik.com/wiki/First_time_startup
In c ase y ou w ish t o b oot t he d evice f rom n etwork, f or e xample t o u se M ikroTik N etinstall, h old t he R ESET b utton
of t he d evice w hen s tarting i t u ntil t he L ED l ight t urns o ff, a nd M etal w ill s tart t o l ook f or N etinstall s ervers.
Extension S lots a nd P orts
Five i ndividual 1 0/100 E thernet p orts, s upporting a utomatic c ross/straight c able c orrection ( Auto M DI/X),
•
so y ou c an u se e ither s traight o r c ross-­‐over c ables f or c onnecting t o o ther n etwork d evices. T he F irst
Ethernet p ort a ccepts 8 -­‐30V D C p owering f rom a p assive P oE i njector.
One I ntegrated W ireless 2 .4GHz 8 02.11b/g/n, 1 x1 M IMO w ith t wo o nboard P IF a ntennas, m ax g ain 1 .5dBi
•
One U SB 2 .0 p ort
•
See www.routerboard.com for more information. Contact support@mikrotik.com for support questions. 30-May-2012
