Dear Sir or Madam,
thank you for choosing our Iris stove.
Before using your stove, please read this booklet carefully so that you may exploit all its features to the full in complete safety.
Please remember that the 1st ignition must be carried out by the dealer, which verifies the installation and completes the guarantee.
The manufacturer cannot be held liable for any damage deriving from stove use following incorrect installation, incorrect maintenance
or misuse.
SAFETY INFORMATION
The stove is designed to heat the room it is installed in by radiation and by air movement from the front grilles. The heat is genera-
ted by automatic pellet combustion in the •rebox.
The only risks which may derive from use of the stove are linked with non-compliance with the installation instructions, direct
contact with live electrical parts (inside) or with the •re or hot parts (glass, pipes and hot air outlet), and the introduction of
foreign substances. Only use pellets as fuel.
If components fail, the stove is •tted with safety devices which turn it off. This must be allowed to happen without interference.
For correct operation, the stove must be installed in compliance with the instructions on page 16 and the door must not be
opened during operation: combustion is managed automatically so no manual operations are needed.
Never put foreign substances in the •rebox or hopper.
Do not use !ammable products to clean the smoke duct.
Firebox and hopper components must only be cleaned using a vacuum cleaner.
The glass must be cleaned when COLD with a special product (e.g. GlassKamin) and cloth. Do not clean when hot.
Make sure the stove is installed and ignited by a quali•ed dealer, which must also complete the guarantee and take responsibility
for correct installation.
During stove operation, the outlet pipes and door reach high temperatures.
Do not keep objects which are not able to withstand heat in the immediate vicinity of the stove.
NEVER use liquid fuels to light the stove or rekindle the embers.
Do not block ventilation openings in the room where the stove is installed or air inlets in the stove itself.
Do not wet the stove, and do not put wet hands near electrical parts.
Do not •t reducers on the smoke outlet pipes.
The stove must be installed in a suitable place as regards •re regulations, and provided with all the facilities (power supply and
outlet) it requires for correct operation.
Before carrying out any maintenance, disconnect the device from the mains power supply.
- 14
-

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IRIS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for EdilKamin IRIS

  • Page 1 Dear Sir or Madam, thank you for choosing our Iris stove. Before using your stove, please read this booklet carefully so that you may exploit all its features to the full in complete safety. Please remember that the 1st ignition must be carried out by the dealer, which verifies the installation and completes the guarantee.
  • Page 2: Operating Features

    In order NOT to jeopardize stove operation, do NOT burn other substances. The use of other materials (including wood), which can be detected by laboratory analyses, invalidates the guarantee. EdilKamin has designed and tested the stoves for best performance with pellets with the following characteristics: • diameter: 6 - 7 millimetres, •...
  • Page 3: Electrical Specifications

    HEATING SPECIFICATIONS Hopper capacity Ef!ciency 89,2 Available power 3,4/8,3 Time between refuellings (min/max) 7,5/20 hours Fuel consumption (min/max) 0,7/2,0 kg/h Heatable room dimensions (min/max) * 115/230 Weight including packaging (min/max) 149/174 Smoke duct diameter (A male) Air intake duct diameter (B male) * The heatable room dimensions are calculated on the basis of pellets with an lhv of at least 4300 kcal/kg and home insulation in compliance with Italian law 10/91.
  • Page 4 ASSEMBLY AND INSTALLATION (Dealer) Refer to the local regulations in the country of use for anything not expressly shown. If the stove is to be installed in a block of •ats, consult the block administration before installing. COMPATIBILITY CHECK WITH OTHER DEVICES The stove must NOT be installed in the same room as extractor fans or type B gas equipment.
  • Page 5 A: insulated steel •ue Distance from •ammable material Floor protection B: 1.5 m minimum height C-E: air intake from inside room (minimum internal section: 80 cm2) D: steel •ue, inside existing brick-built chimney - 18...
  • Page 6: Installation Instructions

    COVERINGS Model with ceramic or ollite side covering. Covering parts list: • 1 side tiles (4 pcs) • 2 side aluminium panels (4 pc) • 3 cast iron top • 4 pellet hopper cover • 5 top tiles • 6 cast iron base After positioning the frame according to the instructions shown in the INSTALLATION INSTRUCTIONS...
  • Page 7: Operation

    Panel On/Off key To turn the stove on or off. Panel A/M key For switching stove operation from manual to automatic and vice versa. Only on IRIS WITH WEEKLY PROGRAMMER Panel “hourglass” key For setting the programmed on/off times left knob...
  • Page 8 SCREW FEEDER LOADING. If the pellet hopper empties completely, press the On/Off and A/M keys simultaneously to •ll the screw feeder. This must be done before igniting the stove again if it has shut down due to running out of pellets. It is normal for a few pellets to be left in the hopper, which the screw feeder is not able to pick up.
  • Page 9 WEEKLY TIME PROGRAMMER BUILT INTO PANEL The concept of the weekly time programmer built into the central panel It is possible to set 3 ignition programmes Pr01 with settable on and off times Pr02 with settable on and off times Pr03 with settable on and off times It is possible to enable one or more of the three programmes on each day of the week (day1 = Monday, day2 = Tuesday…day7 = Sunday).
  • Page 10 ADVICE IN THE EVENT OF PROBLEMS PROBLEM CAUSE SOLUTIONS make sure the power cord is connected display-control panel off no mains voltage check the fuse (on the power socket) excessive distance from stove move nearer stove remote control (optional) not working remote control battery !at check battery and replace if necessary outlet air not hot...
  • Page 11 ADVICE IN THE EVENT OF PROBLEMS H1) Low pressure alarm (this trips if the •ow sensor detects insuf•cient combustion air •ow) The •ow may be insuf•cient because the door is open, the door does not close properly (e.g. bad seal), there is an air intake or smoke extraction problem, or the combustion chamber is clogged.
  • Page 12: Daily Cleaning

    CE STANDARDS and COMPLIANCE DECLARATION The IRIS stove is certi•ed according to standards prEN 14785 and EC 50165 EdilKamin declares that the IRIS stove complies with the following C.E. marking European Directives 73/23/EEC and later modi•cation 93/68/EEC 89/336/EEC and later modi•cations 93/68/EEC...
