- Page 1 E-1316 REV A 09/01/18 FCC-4, FCC-5, FCC-6 Non-Refrigerated Models Installation & Operation Instructions KEEP THIS MANUAL FOR FUTURE REFERENCE Engineering and technical data are subject to change without notice FEDERAL INDUSTRIES 215 Federal Avenue Belleville, WI 53508 Toll Free 1(800)356-4206...
-
Page 2: Table Of Contents
DOORS……………………………………………………………………………………………………..….10 PLACING PRODUCT INTO CASE……………………………………………………………………..….10 REAR STORAGE AREA…………………………………………………………………………………….10 CLEANING INSTRUCTIONS…………………………………………………………...…11 DAILY CLEANING…………………………………………………………………………………………….11 WEEKLY CLEANING…………………………………………………………………………………………11 INTERIOR CLEANING………………………………………………………………………………………..12 EXTERIOR CLEANING……………………………………………………………………………………….12 SERVICE INFORMATION……………………………………………………………...….13 PRE-SERVICE CHECKLIST…………………………………………………………………………….…..13 SALE & DISPOSAL……………………………………………………………………..…14 OWNER RESPONSIBILITY……………………………………………………………………………...…..14 ELECTRICAL DATA……………………………………………………………………..…14 REPLACMENT PARTS…………………………………………………………………….15 WIRING DIAGRAM – FCC-4 & FCC-5…………………………………………………..16 WIRING DIAGRAM- FCC-6………………………………………………………………..17... -
Page 3: Introduction
INTRODUCTION Thank you for purchasing a Federal Industries display case. This manual contains important instructions for installing and servicing the Chocolate & Confectionery Display Cases. A reapri parts list and wiring diagram are also included in the manual. Read all of these documents carefully before installing or servicing your case. -
Page 4: Warning Lables & Safety Instructions
This is important installation, operation, or service information. If you ignore the message, you may damage your case. The warning and saftey labels are shown thoughout this manual are place on your Federal Industries case at the factory. Follow all warning label instructions. If any warning or saftey labels become lost or damaged, call our customer service department at 1(800)354-4206 for replacements. -
Page 5: Pre-Installation Procedures
PRE-INSTALLATION PROCEDURES Inspection for Shipping Damage You are responsible for filing all freight claims with the delivering truck line. Inspect all cartons and crates for damage as soon as they arrive. If damage is noted to shipping crates or cartons or if a shortage is found, note this on the bill of lading (all copies) prior to signing. If damage is discovered when the case is uncrated, immediately call the delivering truck line and follow up the call with a written report indicating concealed damage to your shipment. -
Page 6: Grill Removal
Grill Removal DANGER: Electrical shock hazard. Do not operate unit with panels removed. There is a removable slotted panel at the rear of the case. The panel allows access to the light ballast and the field wiring connection box. Remove this panel to make field wiring connections. -
Page 7: Shelving
Shelving The case is equipped with three tiers of adjustable glass shelves. The deepest shelf is at the bottom and the shallowest at the top. Each tier is supported by three (3) shelf brackets. Turn the shelf light switch “off”. Remove both rear doors from the track by lifting them upward until the bottom edge clears the lower door track and then outward. -
Page 8: Electrical Information & Grounding
ELECTRICAL INFORMATION & GROUNDING THIS CASE MUST BE GROUNDED DANGER: Improper or faulty hookup of electrical components in the display case can result in severe injury or death. All of the case electrical connections must be performed only by a licensed electrician. All electrical wiring hookups must be done in acordance with all applicable local, regional, or national standards. -
Page 9: Operating Instructions
OPERATING INSTRUCTIONS Initial Start-Up After all the checks outlined in the installation section of this manual have been made, the case is ready to be put into service. Chocolate/Confectionery Display Conditions An air circulation fan is provided to reduce the heat buildup when the shelf lights are on. Controls Light Switch This switch controls the power to the lighting circuit. -
Page 10: Light Replacement
Light Replacement The light fixtures use a spring loaded socket on one end. To remove a light, push the bulb toward the spring-loaded socket until the opposite end drops out of the socket. The bulbs are furnished with plastic safety light shields. Make certain the light shields are always in place to safeguard against bulb breakage. -
Page 11: Cleaning Instructions
CLEANING INSTRUCTIONS Daily Cleaning The case should be cleaned thoroughly, as described in the weekly cleaning section, before it is used for the first time. NOTICE: Avoid splashing or soaking any electrical components with water to prevent electrical damage to the case. NOTICE: Shut off light and fan switches and remove all product from case. -
Page 12: Interior Cleaning
Interior Cleaning 1. Remove rear doors from track by lifting door upward until the bottom of the door clears the lower door track and then outward. Remove the inner door in the same manner. 2. Remove all shelves from the case by sliding them rearward and through the door opening. 3. -
Page 13: Service Information
Service problems or request for repair parts from authorized service agencies, trained service personnel, or owners should be referred to: Warranty/Technical Service Department Federal Industries Toll Free (800)356-4206 WI Phone (608)424-3331 geninfo@federalind.com... -
Page 14: Sale & Disposal
SALE & DISPOSAL Owner Responsibility If you sell or give away your Federal Industries case you must make sure that all safety labels and the Installation-Service manual are included with it. If you need replacement labels or manuals, Federal Industries will provide them free of charge. Contact the Customer Service Department at Federal Industries at (800)356-4206. -
Page 15: Replacment Parts
REPLACEMENT PARTS MODEL FCC-4, FCC-5, FCC-6 Part Description Part Number Electrical Components FCC-4 FCC-5 FCC-6 Power or Light Switch 41-11066 41-11066 41-11066 Ballast 39-12904 39-12904 39-12903 Light Bulb 42-11069 42-11070 42-11071 Light Socket (stationery) 42-10834 42-10834 42-10834 Light Socket (spring loaded) -
Page 16: Wiring Diagram- Fcc-4 & Fcc-5
WIRING DIAGRAM- FCC-4 & FCC-5... -
Page 17: Wiring Diagram- Fcc-6
WIRING DIAGRAM- FCC-6 California Residents Only. WARNING This product can expose you to chemicals including chromium which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov...
