Digital Lumens RLE-D1 Installation Instructions Manual

Hide thumbs Also See for RLE-D1:

Advertisement

RLE
IMPORTANT SAFEGUARDS – RLE
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ THESE INSTRUCTIONS BEFORE USING THIS PRODUCT.
Product Safety
This product must be installed in accordance with the applicable
!
installation codes by a person familiar with the construction and
operation of the product and the hazards involved.
To avoid risk of electrical shock, disconnect power before installing,
wiring, or servicing the fixture.
The light source contained in this luminaire shall only be replaced by
the manufacturer or his service agent or similarly qualified person.
Do not apply paint, lubricants or other coatings to fixture,
!
suspension cables, or fasteners.
If you attach a safety cable, attach it to the fixture in accordance
!
with all national, state, and local construction codes.
Do not use fixture if the housing, aircraft cables, optics, or power
!
cable are damaged.
SAVE THESE INSTRUCTIONS.
Do not touch optical lenses with your fingers or hands. In the event
!
you need to clean the lens, use a damp cloth and gently swab the
affected area.
Only handle fixture by sheet metal surfaces. Do not grasp or handle
!
by the fixture lenses or light bars.
Suitable for indoor use only.
!
