Specifications; Construction Specifications - Invicta REMILLY Specific User And Installation Manual

Please read this additional specific manual and the general manual also provided with the appliance carefully
Specifications as per EN 13240:
Rated power
Efficiency
CO Rate%
Flamme Verte classification
Released dust concentration at 13% of O
Smoke temperature
Recommended fuel
Smoke mass flow
Floor protection
The appliance must not be placed directly on flooring made of combustible materials or that could be damaged by heat.
If this occurs, place the appliance on a 50 cm wide and 50 cm long concrete slab, 45mm thick, covered with a reflective
surface on the appliance side (stainless steel type plate or plate with a glossy ceramic surface), the appliance should be
in the middle of this slab.
Minimum distance from adjacent combustible materials: 60 cm
If the neighbouring walls are made from non-combustible materials that are not damaged by heat (the wall temperature
can reach 200°C), these distances can be reduced to 15 cm.
Extended combustion

Construction specifications:

Appliance weight
Connection to the chimney flue using the nozzle
on the top of the appliance
Dimensions
Door dimensions
Window dimensions
Identification plate
XD, le 03/07/2019
Wood stove REMILLY
Specific user and installation manual
2
366
h 800 mm
h 489 mm
h 326 mm
7 kW
0.08 %
21 mg/Nm
318 °C
Wood / 25 cm logs
maximum possible length (horizontally): 34 cm
5.6 g/s
8 hours
150
410
72 kg
diameter 150 mm
len 436 mm
Engraved on the underside of the ash pan
Référence: 601384
Code 1
78 %
3
depth 364 mm
len 328 mm
len 228 mm
Page 2 of 9
