Select The Recording Mode (Optional); Start Recording; Turn Off Camera; Led Status Indicators - Mobius Quick Start Manual

Select the recording Mode (optional)

The Mode button enables the camera to be sequentially switched between 4 different modes. Each
button press advances to the next mode indicated by the LED color.
•
Video Mode 1 (yellow LED). Standard configuration is 1080p video with 30 fps and large AOV with
non-rotated video.
•
Video Mode 2 (blue LED). Standard configuration is 720p video with 60 fps and small AOV with
non-rotated video.
•
Photo Mode (red LED). Standard configuration is 2304 x 1536, no time-lapse.
•
Playback Mode (red LED) is only possible when the special A/V-out cable is connected.

Start Recording

Press the shutter button to start or end a video recording, to take a picture or to play/pause when in
Playback mode. Playback mode is only available when the A/V cable is attached and is described in the
Mobius Instruction Manual.

Turn off Camera

Press and hold the Power Button for about half a second and then release it. The red LED will blink 3
times and the camera will turn off.

LED status indicators

Since the camera has many functions, it's important to understand the meaning of the LEDs. The
following LED states are for a camera not connected to the PC.
Yellow LED remains on:
•
The camera is in Video Mode 1 and is on standby.
Yellow LED slowly flashes (1 sec. On, 1 sec. Off):
•
The camera is in Video Mode 1 and is recording video. The Video Recording indicator is turned ON
in the standard configuration.
Blue LED remains on:
•
The camera is in Video Mode 2 and is on standby.
Blue LED slowly flashes
•
The camera is in Video Mode 2 and is recording video. The Video Recording indicator is turned ON
in the standard configuration.
Red LED remains on:
•
Camera is in Photo Mode or Playback Mode (if an A/V cable is connected) and is on standby.
Red LED flashes once
•
The camera has taken a picture
Green LED is on:
•
The battery is charging. The green LED may only be visible when the other LEDs are off.

The rear LED

When the camera is turned on, the rear LED will blink one to three times to indicate the battery charge.
Three blinks indicate a full battery, whereas one blink indicates the battery charge is getting low.

Connecting the camera to the PC

Make sure the camera is turned OFF if you want to access the camera as an external device (disk drive,
setup). Always connect the camera directly to the PC. Do not use a USB hub.
This manual was last updated on 15 October 2013
(1 sec. On, 1 sec. Off):
