Table 5: MIG3500 Accessories Ordering Information
Product Code Description
Number
Y65T31-0 Power transformer (Class 2, 24 VAC, 40 VA maximum output), no enclosure
- Power transformer (Class 2, 24 VAC, 50 VA maximum output), no enclosure
AS-XFR050 0
EN-EWC25-0 Standard enclosure with dimensions: 406 x 406 x 190 mm (16 x 16 x 7.5 in.)
MM-CVT101-0 RS232 to RS485 Converter (old style)
AS-CVTPRO300-1 Zone Bus/N2 Bus Interface Converter with 120 VAC/3 VDC External Power Adapter (North American
version)
IU-9100-8401 RS232 to RS485 Interface Unit (European use only)

Technical Specifications

MIG3500 Model
Power Requirement
Power Consumption
Ambient Operating Temperature
Ambient Operating Conditions
Ambient Storage Temperature
Ambient Storage Conditions
Battery
Processor
Memory
Operating System
Network and Serial Interfaces
Dimensions
(Height x Width x Depth)
Housing
Mounting
Shipping Weight
Compliance
The performance specifications are nominal and conform to acceptable industry standard. For application at conditions beyond these
specifications, consult the local Johnson Controls® office. Johnson Controls, Inc. shall not be liable for damages resulting from misapplication
or misuse of its products.
Metasys Integrator® MIG3500 Series Installation Instructions
Dedicated nominal 24 VAC, Class 2 power supply (North America), Safety Extra-Low
Voltage (SELV) power supply (Europe), at 50/60 Hz (20 VAC minimum to 30 VAC
maximum)
25 VA maximum
0 to 50°C (32 to 122°F)
10 to 90% RH, 30°C (86°F) maximum dew point
-40 to 70°C (-40 to 158°F)
5 to 95% RH, 30°C (86°F) maximum dew point
Non-rechargeable lithium 3.0 V, 160 mAh; typical life of 5 to 7 years at 21°C (70°F)
Panasonic® CR2025 or equivalent
192 MHz Renesas™ SH4 7760 RISC processor
128 MB Flash nonvolatile memory
128 MB Synchronous Dynamic Random Access Memory (SDRAM)
Microsoft® Windows® CE embedded
One Ethernet port; 10/100 Mb/s; 8-pin RJ-45 connector
One optically isolated RS-485 port; 9600 bps; pluggable and keyed 4-position terminal
block
Two RS232C serial ports with standard 9-pin sub-D connectors that support standard
baud rates.
131 x 270 x 62 mm (5.2 x 10.6 x 2.5 in.)
Minimum space for mounting: 210 x 350 x 110 mm (8.3 x 13.8 x 4.3 in.)
Plastic housing material: ABS + polycarbonate; Protection: IP20 (IEC60529)
On flat surface with screws on three mounting clips or a single 35 mm DIN rail
1.2 kg (2.7 lb)
United States
UL Listed (PAZX), UL 916
FCC compliant, CFR47, Part 15, Class B
Canada
UL Listed (PAZX7), CAN/CSA C22.2 No. 205
Industry Canada compliant
Europe
EMC Directive, 89/336/EEC
Australia/New Zealand
C-Tick mark compliant
