Cisco ATUC-4DMT-ISDN Installation And Configuration Manual

Line card.
Hide thumbs

Advertisement

Cisco ATUC-4DMT-ISDN Line Card
Installation and Configuration
Product Number: ATUC-1-4DMT-I(=)
Introduction
This publication contains instructions that describe how to install and configure
Cisco ATUC-4DMT-ISDN line cards. This high-density line card supports discrete multitone (DMT)
over Integrated Services Digital Network (ISDN) protocols that employ 2B1Q- or 4B3T-based
encoding.
You can only use this line card in Cisco 6260 digital subscriber line access multiplexers (DSLAMs) that
contain the NI-2 network interface processor module running Cisco IOS software. You can deploy the
line cards described in this document in either of two ways:
A direct connect configuration—Telco equipment routes DMT signals only between customer
modems and the line cards (see the "Line Card Direct Connect Deployment" section on page 11).
A splitter configuration—Telco equipment includes DMT/ISDN splitters to separate or combine
ISDN and DMT signals at the central office (CO) and at the customer site (see the "Line Card
Splitter Deployment" section on page 13).
Corporate Headquarters: Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
Copyright © 2000. Cisco Systems, Inc. All rights reserved.
78-10981-01

Advertisement

Table of Contents

   Related Manuals for Cisco ATUC-4DMT-ISDN

   Summary of Contents for Cisco ATUC-4DMT-ISDN

  • Page 1 Integrated Services Digital Network (ISDN) protocols that employ 2B1Q- or 4B3T-based encoding. You can only use this line card in Cisco 6260 digital subscriber line access multiplexers (DSLAMs) that contain the NI-2 network interface processor module running Cisco IOS software. You can deploy the line cards described in this document in either of two ways: •...
  • Page 2: Table Of Contents

    Cisco Documentation Feedback, page 20 • Line Card Description You can only use ATUC-4DMT-ISDN line cards in ISDN service in Cisco 6260 DLSAM chassis. In a direct connect configuration—DMT signals are routed directly between the line cards and the •...
  • Page 3: Safety

    Para ver as traduções dos avisos que constam desta publicação, consulte o documento Regulatory Compliance and Safety Information (Informação de Segurança e Disposições Reguladoras) que acompanha este dispositivo. Cisco ATUC-4DMT-ISDN Line Card Installation and Configuration 78-10981-01...
  • Page 4 If you plan to return the component to the factory, immediately place it in a static-shielding container. Avoid contact between the printed circuit boards and clothing. The wrist strap protects components • from ESD voltages on the body only; ESD voltages on clothing can still cause damage. Cisco ATUC-4DMT-ISDN Line Card Installation and Configuration 78-10981-01...
  • Page 5: Installation Prerequisites

    Installing and Removing Line Cards To install any line card in a Cisco 6260 DSLAM chassis, follow the procedures in the “Line Card Installation” section on page 5. To remove a line card, follow the procedures in the “Line Card Removal”...
  • Page 6 Installing and Removing Line Cards Slot 11 and any other empty Cisco 6260 NI-2 DSLAM slot—Must contain a blank faceplate (refer • to the Cisco 6260 Hardware Installation and Troubleshooting Guide for details) To install a line card in a Cisco 6260 chassis slot, perform the following steps: Caution Static voltages as low as 30 volts can cause latent damage to circuitry.
  • Page 7 -4DMT ATUC-1 ATUC-1 -4DMT ATUC-1 -4DMT -4DMT -4DMT The Cisco 6260 Hardware Installation and Troubleshooting Guide describes the Cisco 6260 Note DSLAM-slot modem tip and ring mapping to backplane connectors. Figure 2 Typical Line Card Locking Tab Locked Unlocked position...
  • Page 8 This section describes how to remove a line card. You do not need to disconnect power before you remove a line card from its slot in a Cisco 6260 DSLAM chassis. The following procedure describes how to remove a line card.
  • Page 9: Line Card Faceplate Description

    The Status and Active light-emitting diode (LED) indicators on the line card faceplate indicate line card activity during operation. The faceplate also includes four modem-status LED indicators, one for each modem in the line card. Table 2 describes LEDs on the ATUC-4DMT-ISDN line card. Table 2...
  • Page 10 For Cisco IOS software configuration information and support, refer to the Configuration Guide for Cisco 6000 Family DSLAMs with NI-2 and to the Command Reference for Cisco 6000 Family DSLAMs with NI-2 in the Cisco IOS software configuration documentation set that corresponds with the software release installed on your Cisco 6260 NI-2 DSLAM hardware.
  • Page 11: Line Card Direct Connect Deployment

    In direct connect deployments, Cisco ATUC-4DMT-ISDN line cards are a principal component of the Cisco 6260 DSLAM normally located in a CO facility rack. You install from 1 to N (where N has any value up to 30) line cards in a single Cisco 6260 DSLAM.
  • Page 12 Cisco 677i Modem At a customer site, you must use the Cisco 677i modem to provide the Ethernet LAN interface (see Figure 4) at the downstream end of the line. The 677i modem provides the interface between a customer Ethernet and a line card.
  • Page 13: Line Card Splitter Deployment

    A full complement of line cards in a single Cisco 6260 DSLAM can handle network communications from and to as many as 120 customers. You can install up to four Cisco 6260 DSLAMs, populated with ATUC-4DMT-ISDN line cards in a direct connect configuration, in a standard NEBS compliant 7-foot CO facility rack.
  • Page 14 In DMT/ISDN line card deployments, you use CPE and CO splitters to separate the two signals. DMT/ISDN splitters permit both telephone voice and data signals to be transported as data from and to the CPE. You can install as many as 30 ATUC-4DMT-ISDN line cards in a single splitter-configured Cisco 6260 DSLAM.
  • Page 15 2B1Q or 4B3T signals (see Table 3) to the splitter. Cisco 677i Modem In this deployment, the Cisco 677i modem (seeFigure 5 ) also provides the Ethernet primary interface. The Cisco 677i modem transmits and receives DMT signals or Ethernet data passed between the local DMT/ISDN CPE splitter and the customer LAN.
  • Page 16 Line Card Splitter Deployment Feeds the line card downstream DMT signal to the Cisco 677i modem for conversion to equivalent • Ethernet data for application to the customer LAN Combines upstream ISDN and DMT signals from the subscriber modem into a DMT/ISDN data •...
  • Page 17: Acronyms And Terms

    Acronyms and Terms Cisco NI-2 Network Interface Processor Module The “Cisco NI-2 Network Interface Processor Module” section on page 13 briefly describes the Cisco NI-2 network interface processor module (see Figure 4 and Figure 5). Acronyms and Terms Table 3 defines the following terms that are used in this guide.
  • Page 18: More Information

    Virtual channel identifier Virtual path identifier Visible More Information Your Cisco 6260 NI-2 DSLAM and Cisco IOS software running on an NI-2 module installed in Cisco 6260 NI-2 DSLAMs have extensive features and functionality, which are documented in the following resources: •...
  • Page 19: Cisco Connection Online

    You can determine whether your equipment is causing interference by turning it off. If the interference stops, it was probably caused by the Cisco equipment or one of its peripheral devices. If the equipment causes interference to radio or television reception, try to correct the interference by using one or more of the following measures: Turn the television or radio antenna until the interference stops.
  • Page 20: Documentation Cd-rom

    For a copy of CCO Frequently Asked Questions (FAQ), contact cco-help@cisco.com. For additional information, contact cco-team@cisco.com. If you are a network administrator and need personal technical assistance with a Cisco product that is under warranty or covered by a maintenance contract, contact the Cisco Technical Assistance Center (TAC) at 800 553-2447, 408 526-7209, or tac@cisco.com.
  • Page 21 Cisco Systems, Inc. or its affiliates in the U.S. and certain other countries. All other brands, names, or trademarks mentioned in this document/website are the property of their respective owners. The use of the word partner does not imply a partnership relationship between Cisco and any of its resellers.
  • Page 22 Cisco Documentation Feedback Cisco ATUC-4DMT-ISDN Line Card Installation and Configuration 78-10981-01...
