W he r e T h e re is Miboxer There is Po wer
User Instruction
Model No.: C2-4000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C2-4000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Miboxer C2-4000

Summary of Contents for Miboxer C2-4000

  • Page 1 W he r e T h e re is Miboxer There is Po wer User Instruction Model No.: C2-4000...
  • Page 2 Introduction C2-4000 is a charger, capable of charging and charge-discharge-charge batteries. The charger automatically adapts the charge and discharge current, according to characteristics of each battery. During the charging process, it will automatically determine the battery capacity, internal resistance, the remaining charging time, the battery percentage, charging voltage, charging current, temperature and so on.

  • Page 3: Lcd Display Introduction

    Parameters Input voltage: DC 12V 2A Output voltage: 4.20V±1% /4.35V±1% / 3.6V±1% / 1.48V±1% Output current: Li-ion maximum 2*1.5A Ni-MH/Ni-Cd maximum 2*1A Products weight: 215g Compatible with: Li-ion(4.2V/4.35V) (IMR/INR/ICR) / LiFePO4(3.6V) 10340 / 10350 / 10440 / 10500 / 12340 / 12500 12650 / 13450 / 13500 / 13650 / 14350 / 14430 14500 / 14650 / 16500 / 16340(RCR123) / 16650 17350 / 17500 / 17650 / 17670 / 18350 / 18490...

  • Page 4: Battery Capacity

    Battery percentage After battery was placed in one of the charging slots, the charger will display the battery percentage automatically. Remaining time / charging time / total charge-discharge-charge time Constant shinning, means the remain charging time; Constant shinning, means the total time. Note: During battery discharge mode, the time reading means the cumulative time.

  • Page 5: Battery Type Selection

    Operating Instructions 1. Put the battery in any channel, the charger starts to detect the related data of the battery and display it on the LCD screen. After 5 seconds, the most suitable current charge (maximum 1.5A, minimum 0.1A) is automatically selected according to the battery characteristics.

  • Page 6: Time Display

    Charge-discharge-charge to measure the battery capacity Hold the key till “ ” flickering, and press the key within 3 seconds, to switch measurement functions. “ ” disappear means measurement functions shut down. “ ” display means measurement functions turn on，the charger will charge the battery, and then discharge, real-time calculation of battery capacity and save the data, after the end of the discharge, once again the battery is...

  • Page 7: Function Description

    Function Description Automatically set the charging current After a battery is inserted into any of the charging slots, the charger will automatically set the most suitable charge current according to the battery characteristics. MAX 1.5A / MIN 0.1A. Li-ion(4.2V / 4.35V) battery When the battery voltage is below 3.60V, The charger automatically selects the appropriate trickle current according to the...

  • Page 8: Matters Needing Attention

    Battery activation function If the charger will identify a protected lithium battery that needs to be activated due to under-voltage, it will attept to activate it in accordance with the standard charging method.. If the charger will not be able to activate the battery, it will be considered to be damaged, corresponding channel prompt “...
  • Page 9 2. Using environment: using temperature -10~40℃, storage temperature: -20~60℃, please do not store the charger directly in the sunlight, near the heating equipment or other high temperature sources. 3. The charger is suitable for adults over 18 years old; children using the charger must be under the supervision of adults.

  • Page 10: Warranty & Service

    For the latest information on products and services, please contact a local distributor or send an email to sales@miboxer.com. Packing list Name Quantity C2-4000 Charger 1 PC User Manual 1 PC AC TO DC 12V/2A 1 PC Power Supply Made in China...
  • Page 11 Scan for more MiBoxer Hi-Tech Co.,Ltd. Add: Floor 2, Buiding D, Fusen Technology Park, Hangcheng Road, Bao’an District, Shenzhen City, Guangdong Province, China E-mail: sales@miboxer.com http://www.miboxer.com...
