DOREL ASIA
SOFA
CONTAINS
INFORMATION. PLEASE READ AND
KEEP FOR FUTURE REFERENCE.
DO NOT RETURN PRODUCT TO THE STORE.
If a part is missing or damaged, contact our customer service
department. We will replace the part FREE of charge.
0-65857-16500-5
THIS INSTRUCTION BOOKLET
IMPORTANT
(TAKEN FROM CARTON)
___________________
Date of purchase:
_______ / _______ / _______
Tel #: 1-800-295-1980
NEED HELP!
E-Mail: das@dorel.com
CALL US FOR ASSISTA
1-800-295-1980
Fax #: 514-353-7819
DO NOT RETURN PROD
E-MAIL:DAS@DOREL.C
Model No.:
DA3350-SF
UPC CODE:
NOTE:
SAFETY
Lot number:
Advertisement
Table of Contents
Related Manuals for Dorel Asia DA3350-SF
Summary of Contents for Dorel Asia DA3350-SF
- Page 1 DOREL ASIA SOFA Model No.: DA3350-SF UPC CODE: 0-65857-16500-5 NOTE: THIS INSTRUCTION BOOKLET IMPORTANT CONTAINS SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Lot number: (TAKEN FROM CARTON) ___________________ Date of purchase: _______ / _______ / _______ DO NOT RETURN PRODUCT TO THE STORE.
-
Page 2: Care And Cleaning
Check bolts/screws periodically and tighten them if necessary. LIMITED WARRANTY Dorel Asia warrants its product to be free from defects in material and workmanship and agrees to remedy any such defect. This warranty covers 1 year from the date of original purchase. -
Page 3: Hardware List
SOFA DA3350-SF HARDWARE LIST Ø5/16" X 45mm Ø22 X 1.5mm Ø12.5 X 1.2mm HEX SOCKET HEAD BOLT FLAT WASHER SPRING WASHER 8 PCS 8 PCS 8 PCS ALLEN KEY 1 PC... -
Page 4: Parts List
SOFA DA3350-SF PARTS LIST SOFA BACK LEFT ARM RIGHT ARM 1 PC 1 PC 1 PC FRONT PANEL SEAT PANEL FOOT 1 PC 1 PC 4 PCS SEAT CUSHION PLASTIC WASHER 3 PCS 4 PCS... - Page 5 SOFA DA3350-SF STEP 1: Place sofa back (A) on a clean surface. Lift the fabric lining underneath the sofa back (A). Attach left arm (B) and right arm (C) to sofa back (A) with hex socket head bolts (1), flat...
- Page 6 SOFA DA3350-SF STEP 2: Install hex socket head bolts (1), flat washers (2) and spring washers (3) into sofa arms (B & C). DO NOT tighten the bolts. Leave them extended about half an inch (see photo below). Bolts extended 1/2"...
- Page 7 SOFA DA3350-SF STEP 3: Hook front panel (D) to left arm (B) & right arm (C) as shown below. Push front panel (D) with a downward force to lock it into place. Secure front panel (D) to arms (B&C) by tightening the hex socket head bolts (1) with Allen...
- Page 8 SOFA DA3350-SF STEP 4: Gently lay down the assembled unit on its sofa back (A). Attach feet (F) to the arms (B) & (C) with plastic washers (H) by rotating clockwise.
- Page 9 SOFA DA3350-SF STEP 5: Turn the assembled unit upright. Place seat panel (E) on the assembled frame.
- Page 10 SOFA DA3350-SF STEP 6: Place seat cushions (G) on the seat panel (E).
- Page 11 SOFA DA3350-SF CAUTION: This unit is intended for use only with the products and/or maximum weights indicated. Use with other products and/or products heavier than the maximum weights indicated may result in instability or cause possible injury. Dust leather regularly with a clean, dry cloth to avoid soil build-up.
- Page 12 MODEL #: DA3350-SF (Black) Customer Service PLEASE DO NOT RETURN THIS PRODUCT TO THE STORE PLEASE CONTACT CUSTOMER SERVICE REPRESENTATIVES AT THE FOLLOWING NUMBERS SHOULD THERE BE ANY MISSING OR DEFECTIVE PART(S). Customer Service Phone Number 1-800-295-1980 Email: das@dorel.com Customer Service Fax Number 514-353-7819...
