REVENTON VELO Silver Series User Manual

Domestic axial fan with throttle
VELO and VELO Silver series
User Manual

Introduction

Thank you for choosing our product. Reading of this manual
is required for proper use of the device and absolute
observance to its guidelines is fundamental condition
of security.
All users of the device should have free access
to the manual and in case of resale, the instruction must
be attached to the product.

Package contents

- domestic axial fan VELO
- user manual

Transport and storage

The fan should be transported and stored in the original
packaging in a dry place protected from contamination,
until it is installed. Moreover, the fan should be protected
from the shocks.

Application

Axial fans from the VELO series are designed for wall
mounting. They are used for ventilation of small spaces
such as a bathroom or kitchen.
The device comes in two colors - white or silver (VELO Silver
version).

Construction of the device

1 – Panel 2 – Sensor
4 – Motor 5 – Rotor ,w
7 – Throttle 8 – Fastening ring

Dimensions (in mm)

MODEL ØA
VELO 100 & VELO SILVER 100 100
VELO 150 & VELO SILVER 150 150

Technical data

Maximum aiflow [m
Maximum compression [Pa]
Voltage [V] / Frequency [Hz]
Rated current [A]
Engine speed [rpm]
Engine power [W]
IP protection degree [-]
Noise [dB(A)]

Installation instructions

In order to accomplish the installation of the device
successfully and enable the safe usage of the fan
in the future, it is essential to follow the instructions in this
manual.
Before installing and connecting the fan, check that it has
not been damaged during transport or storage (breakage,
distortion).
Check whether the technical data on the nameplate
corresponds to the electrical installation parameters.
The device should be mounted on a flat surface.
If irregularities are not found, you can proceed
with the installation as follows:
3 – Casing
- prepare appropriate electrical wires
6 – Throttle frame
- mark the location of mounting holes
9 - Frame
- drill the holes and put expansion bolts in them
- place the fan in the right place and tighten screw it
- connect the device to electrical grid
The electrical connection must be in accordance
with the wiring diagram in the terminal box.

Warnings and precautions

During the operation of the device, the following
precautions must be observed:
- before performing any work, the device must
B C D
be disconnected from the power supply
150 90 35
- the fan is intended only for ventilation of rooms with small
193 100 35
and medium cubature
- if you do not use it for a long time, it is recommended
to disconnect the device from the power supply
VELO 100 & VELO 150 &
MODEL
VELO Silver 100 VELO Silver 150
3 /h]
95
36
230 / 50 - 60 230 / 50 - 60
0.072
2400
12
X4
34
240
60
0.138
2000
18
X4
35
