5. Specifications

5.1 General Specifications

Range
Function
Safety Rating
CAT III 600V, pollution degree: II
Operating Altitude
<2000m
Operating Temperature/
0~40°C, <80% RH
Humidity
Storage Temperature/
-10~60°C, <70% RH, remove battery
Humidity
Temperature
0.1xaccuracy/°C (>18°C or <28°C)
coefficient
Max. Input between
terminals and earth 600V DC or AC rms
ground
µA/mA ranges: FF 400mA H 600V
Fuse Protection
10A range: FF 10A H 600V
Sample Rate Approx. 3 times/sec.
Display 3 ½ digit LCD display
Display shows "OL"
Overload Indication
When battery voltage drops below
Low Battery Indication
normal operating voltage,"
shown on the display
Polarity Indication Display automatically displays "-"
DC 9V, NEDA 1604 or 6F22
Power Supply
148x73.5x50mm
Size(LxWxH)
about 232g
weight
"is
11

5.2 Technical Specifications

Accuracy: ±(% of reading + digits) at 18°C~28°C with a
relative humidity of <80%; guaranteed for a period of
one year.
5.2.1 DC Voltage
Measuring range
Resolution
200mV 0.1mV
2V 0.001V
20V 0.01V
200V 0.1V
600V 1V
Input impedance: 10MΩ
Max. input voltage: 600V DC or AC rms.
5.2.2 AC Voltage
Measuring range
Resolution
2V 0.001V
20V 0.01V
200V
0.1V
600V 1V
Input impedance: 10MΩ
Max. input voltage: 600V DC or AC rms.
Frequency Response: 40~400Hz, sine wave rms
(avg. response)
Accuracy
±(0.5% of reading +3 digits)
±(0.8% of reading +3 digits)
Accuracy
±(0.5% of reading +5 digits)
±(1.0% of reading +5 digits)
12
