Exibel HP086BUK Manual

Bluetooth LED Keyboard
Art.no 18-8429 Model HP086BUK
38-6997, 38-6998 HB086B, HB086BDE
Please read the entire instruction manual before using the product and then
save it for future reference. We reserve the right for any errors in text or images
and any necessary changes made to technical data. In the event of technical
problems or other queries, please contact our Customer Services.
Safety
• Do not subject the keyboard to knocks and blows.
• Do not place the keyboard where there is a risk that it may fall into water or
other liquids.
• Do not plug in or unplug the USB cable with wet hands.
• Do not place the keyboard close to strong heat sources or expose it to direct
sunlight for prolonged periods.
• Never attempt to tamper with, repair or modify the keyboard in any way.
The built-in battery cannot be replaced.
• Use only the included USB cable for charging the keyboard.
Buttons and functions
1. On/off switch
2. Status indicator
3. Micro-USB port for connecting
a charger cable
4. Charging indicator
Operating instructions
Charging
Note: The keyboard should be charged for at least 4 hours before it is used for
the first time and even when it is used again after a long period of disuse.
1. Connect the included charger lead to the Micro-USB port (3) on the battery
pack and to a computer or other USB charger.
2. The charging indicator (4) will shine red while the battery is charging and go
out when the battery is fully charged.
3. The status indicator light (2) flashes when the battery needs charging.
GREAT BRITAIN - CUSTOMER SERVICE contact number: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk
Establishing a Bluetooth connection with a computer, tablet
or mobile phone
1. Switch the keyboard on using the on/off switch (1) on the bottom of
the keyboard. The status indicator will come on for a few seconds.
2. Press [ Fn ]+[ c ] simultaneously to make the keyboard detectable for other
Bluetooth devices. The status indicator will begin to flash.
3. Activate Bluetooth on the device you intend to connect to the keyboard.
4. The keyboard will now appear on your device as "Bluetooth 3.0 Keyboard",
select it.
5. A password will now appear on your device. Write the password on
the keyboard and press [ ENTER ].
6. The status indicator will now stop flashing to indicate that the devices are
now connected.
Note:
The keyboard can only be paired with one device at a time. If, for example,
you have the keyboard paired with your iPad and then decide to pair it with
your mobile phone or computer instead, you can't just reactivate the previous
connection to your iPad. You will have to delete the keyboard (Bluetooth 3.0
Keyboard) from the list of Bluetooth devices connected to your iPad and then
carry out a new Bluetooth device search to re-establish the connection.
Backlight
Note:
• The key backlight only works when the keyboard is connected to a Bluetooth
device.
• The backlight goes off after about 1 minute of inactivity and comes on again
when any of the keys is pressed.
1
The backlight is controlled by the backlight key.
Press the key repeatedly to select in
the following order:
2 3
• Switch the backlight on
• Increase light intensity
• Switch the backlight off
To change the colour of the backlight
Hold in the backlight key whilst simultaneously pressing [ ▲ ] or [ ▼ ] until
the desired colour has been chosen.
4
The Fn key
You must hold in the Fn key at the same time as you press one of the function
keys [ ►ll ] (play/pause), [ l◄◄ ] (change track) etc. in order for them to work.
The @ sign in iOS
Swedish, Finnish
English
Norwegian
internet: www.clasohlson.co.uk
Power save mode
The keyboard will enter power save mode if it is switched on but has been
inactive for more than 15 minutes.
Holding down any button for 3 seconds will wake the keyboard again.
Care and maintenance
Wipe the keyboard clean with a dry cloth as and when required.
Troubleshooting guide
The keyboard The battery in the keyboard might be discharged,
won't turn on. charge the battery.
The keyboard • Make sure that the Bluetooth connection has been
doesn't work. properly established. Refer to the Establishing
a Bluetooth connection... section above.
• Make sure that no other wireless devices are
interfering with the wireless keyboard connection.
• If the device that you are attempting to connect
the keyboard to is already connected to another
Bluetooth device, this may impair or prevent
the keyboard from pairing with the device.
Disconnect the other (disrupting) wireless device.
Certain special • If the any of the keys do not seem to work when
character keys using the keyboard, it could mean that the language
do not work. setting in your smartphone or tablet is not
correctly set. Check the settings in your device.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.
Specifications
Bluetooth 3.0
Range Max 10 m
Battery 800 mA Lithium
Charging input ≥ 200 mA
Time to full charge Approximately 5 hours
Operating time with backlight < 5 hours
Operating time without backlight < 300 days
Operating temperature −10 to 55 °C
28.1 × 13.5 × 0.5 cm (1.4 cm on back edge)
Size
