Exibel HB087 Operating Instructions Manual

Bluetooth Keyboard
with Touchpad
Art.no 18-8427, 38-6917, 38-6940 Model HB087
Please read the entire instruction manual before using the product and then save
it for future reference. We reserve the right for any errors in text or images and any
necessary changes made to technical data. In the event of technical problems or
other queries, please contact our Customer Services.
Safety
• Never subject the keyboard to high temperatures, dust, heavy vibration,
impacts, humidity or moisture.
• Never place any heavy objects on top of the keyboard.
• Do not place the keyboard where there is a risk that it may fall into water or
other liquids.
• Do not place the keyboard close to a strong heat source or expose it to
direct sunlight for prolonged periods.
• Never attempt to tamper with, repair or modify the keyboard in any way.
Buttons and functions
1 2 6
1. [ Fn ]+[ C ] Activates Bluetooth and makes the keyboard detectable for other
Bluetooth devices.
2. [ ] Switches the touchpad on or off.
3. Caps Lock indicator
4. Bluetooth indicator
5. Flashing keyboard Power On indicator
6. [ ON/OFF ] On/off switch
7. Battery holder (the figure shows the battery holder with the cover removed)
8. USB receiver storage slot (this model does not come with a USB receiver
since it has a Bluetooth function)
GREAT BRITAIN - CUSTOMER SERVICE contact number: 020 8247 9300 e-mail: customerservice@clasohlson.co.uk
Operating instructions
Batteries
1. Remove the cover over the battery holder on the back of the keyboard by
sliding it out in the direction of the arrow.
2. Insert 2 × AAA/LR03 batteries (sold separately). Note the polarity markings on
the bottom of the battery holder to ensure correct insertion.
3. Slide the cover back on.
Establishing a Bluetooth connection with
a computer, tablet or mobile phone
1. Set the [ ON/OFF ] switch on the keyboard to the ON position. The Power On
indicator (5) will light for a few seconds and then flash once every 10 seconds
as long as the keyboard has power.
2. Press [ Fn ]+[ C ] to activate Bluetooth and make the keyboard detectable for
other Bluetooth devices. The Bluetooth indicator (4) will flash.
- Activate Bluetooth on the device you intend to connect to the keyboard.
Refer to the instruction manual of your device for further clarification if
you are unsure.
- The keyboard will now appear on your device as Bluetooth 3.0
Keyboard, select it.
- A password will now appear on your device. Write the password on
the keyboard and press [ ENTER ].
3. The devices are now paired.
3 4 5
Note:
• The keyboard can only be paired with one device at a time.
• If, for example, you have the keyboard paired with your iPad and then
decide to pair it with your mobile phone or computer instead, you can't
just reactivate the previous connection to your iPad. You will have to delete
the keyboard (Bluetooth 3.0 Keyboard) from the list of Bluetooth devices
connected to your iPad and then carry out a new Bluetooth device search to
re-establish the connection.
Power save mode
7 8
• The keyboard will enter power save mode if it is switched on but has been
inactive for more than 15 minutes.
• Holding down any button for 3 seconds will wake the keyboard again.
How to use the touchpad
Use one finger to move
the mouse cursor
English
To scroll To zoom
internet: www.clasohlson.co.uk
Use the buttons beneath the touchpad for left- and right-click respectively. You can
even click directly on the touchpad:
• One finger, once to select
• One finger, twice to double-click
• Two fingers, once to right-click

Care and maintenance

Clean the keyboard carefully by wiping it with a soft damp cloth. Use only mild
cleaning agents, never solvents or corrosive chemicals.

Troubleshooting guide

The keyboard The batteries may be flat. Change batteries if necessary.
won't turn on.
The keyboard • Make sure that a Bluetooth connection has been
doesn't work. properly established.
• Make sure that no other wireless devices are
interfering with the wireless keyboard connection.
• If the device that you are attempting to connect
the keyboard to is already connected to another
Bluetooth device, this may impair or prevent
the keyboard from pairing with the device.
Disconnect the other (disrupting) wireless device.
Certain special • If the any of the keys do not seem to work when
character keys using the keyboard, it could mean that the settings
do not work. in your smartphone or tablet are not correctly set.
Check that the language setting is correct, e.g.
English UK. Refer to the instruction manual of
the device if you are unsure how to change
the language.
Disposal
This product should be disposed of in accordance with local regulations.
If you are unsure how to proceed, contact your local council.

Specifications

Bluetooth 3.0
Batteries 2 × AAA/LR03 (sold separately)
Max range 10 m
Size 35.5 × 13 × 0.5 cm (1.5 cm on the rear edge)
Weight 405 g
