Solar-Powered Charger
Art.no 38-3942 Model OY-340-5A
Please read the entire instruction manual before using the
product and save it for future reference. We reserve the right for
any errors in text or images and any necessary changes made
to technical data. If you have any questions regarding technical
problems please contact Customer Services.
Product description
Solar-Powered Charger. Suitable for mobile phones, MP3
players, cameras, etc. Powerful monocrystalline solar panel
that charges the built-in battery with up to 200 mA. Built-in
1500 mAh lithium polymer battery. Can also be charged via
the USB port. Comes with 10 interchangeable DC connectors
which fit most Sony Ericsson, Nokia, Samsung, LG, iPhone,
iPod, mini-USB and micro-USB devices.
1
2 3 4
1. Solar cell panel.
2. USB IN 5 V (connection for charging the built-in battery
via an external power source).
3. USB OUT 5 V (connection for charging devices via
one of the provided adaptors).
4. Battery status indicator.
5. Push button. Press once to check the charge level of
the charger's built-in battery.
GREAT BRITAIN • customer service tel: 08545 300 9799 e-mail: customerservice@clasohlson.co.uk internet: www.clasohlson.com/uk
10 adaptors
Sony Ericsson Nokia 2.0 mm
Mini-USB
Micro-USB
Features
• Can be charged via a USB port.
• Highly effective microprocessor controlled charging system.
• Fixed voltage and constant charging level.
Use
Charging the solar charger from an external
5
power source
The solar charger's built-in battery can be charged from an
external power source such as a computer, mains adaptor or
car charger via the USB port.
1. Connect the solar charger's USB IN port (2) to the USB port
of the external power source.Press the push button (5) to
start charging.
2. There are LEDs to indicate both charge and battery level.
3. When all 3 LEDs are off, the charger is fully charged.
Samsung Samsung
USB PSP Nintendo DSI
LG iPhone/iPod
Charging the solar charger via the solar panel
Point the solar panel directly at the sun and the solar charger's
built-in battery will start charging automatically.
The charger will be fully charged after about 8 hours,
depending on the intensity of the sunlight.
Charging an external device via the solar charger
1. Select the appropriate adaptor and connect the device
using the provided USB cable.
2. Select a suitable legth of USB cable and connect it as
shown in the picture.
3. Charging will start automatically.
Adaptor
Extension cable
Disposal
Follow local ordinances when disposing of this product.
If you are unsure of how to dispose of this product, please
contact your local authority.
Specifications
Solar cell panel 5 V
Battery 1500 mAh lithium polymer battery
Input voltage 5 V DC, 500 mA
Output voltage 5 V/500 mA
Operating environment 0 °C to + 45 °C
138 × 84 × 13 mm
Size
Weight 158 g
