Simplifix ISOFIX Base parts list:
1 Base
2 Carry handle
3 ISOFIX connector arms
4 ISOFIX connector arms
extension paddle lever
5 ISOFIX connection indicator
6 ISOFIX connection release
handles
7 Plastic ISOFIX guides
8 Infant carrier connection bars
9 Infant carrier connection
indicators
9
YES
NO
4
10
11
10 Support leg
11 Support leg adjuster button
12 Support leg pressure indicators
To remove the infant carrier from
the base use the infant carrier
release handle on the back of the
Simplicity Infant Carrier
8
1
YES
5
NO
YES
NO
2
6
7
12
5
3
