Water Tech Pool Blaster Installation Manual

Your new kit includes:

Motor Box with ON/OFF Button (P30X003LI)
Charger (LC099-3S-US-EU)
There are two sizes of screws used in the
Pool Blaster® MAX Li. While disassembling
the machine, make note of which screw is
used where.
Installation Guide - NiMH to Lithium
®
Upgrading the Pool Blaster® MAX Li/MAX Li CG Motor Box
No cover needed
Need Help? Contact Customer Care at (732) 967-9888

Why did my new motor box kit come with a charger?

This complete kit replaces all of the electronics for the Pool
Blaster® MAX Li/MAX Li CG and will guarantee that your
machine will be repaired and increase the longevity of your
battery.
Your old charger will not work. Please dispose of
your original charger.
You will need the following tools:
Phillips screwdriver or battery
powered screwdriver and a cutting tool
low
(set drill at

STEP 1: Place the unit on a workbench

with the ON/OFF knob facing up. Unscrew
ON/OFF Knob.
torque setting)
1
