Summary of Contents for Cielo Perfect Aire PAJS1
- Page 1 THRU-THE-WALL ACs PORTABLE ACs WINDOW ACs MINI-SPLITS PTACs POWERED BY CIELO...
- Page 2 STEP 1A: UNPACKING AND PLUGGING IN THE CONTROLLER For best results, connect the Perfect Aire Smart Controller by Cielo with the provided USB cable and adapter. Mount your Controller on a wall or place it on the enclosed table stand in the AC/Heat Pump’s line of sight and plug it into a power source.
- Page 3 STEP 1B: PRIOR TO APP INSTALLATION YOUR MOBILE PHONE • Make sure Wi-Fi is turned ON on your Cell Phone. • Make sure you have internet access on your Cell Phone. YOUR WI-FI ROUTER • Make sure you have working internet connection on your Wi-Fi Router. • Make sure there is no proxy server or authentication server configured on your internet connection. - IMPORTANT • Make sure IP isolation or client isolation is turned off on your Wi-Fi Router.
- Page 4 STEP 2A: APP INSTALLATION CIELO HOME APP LOGIN SCREEN • Go to the App Store / Play Store. • In “search” section type “Cielo Home”. • Once “Cielo Home” App is displayed, press the Install button • Open the App after installation is complete. STEP 2B: LOGIN / REGISTER • You can either create a new user account or use the App as an existing user. • As an existing user, enter user name and password; press “Login” button. • If you are a new user, press “Sign Up” button and fill in the information.
- Page 5 STEP 3A: REGISTER CONTROLLER – FOR iOS USERS • The Controller registration process is meant to connect the Perfect Aire Smart Controller by Cielo to your home Wi-Fi network through the Cielo Home App. • To begin registration: • Open “Cielo Home App”. • Tap on “+” in the Home Screen • Press “Begin Registration” in the next screen...
- Page 6 STEP 3A: REGISTER CONTROLLER – FOR iOS USERS (CONTINUED) • Go to your phone settings and open Wi-Fi settings. • Connect to the Wi-Fi that starts with Cielo_BE01_XXXXXX • Next, go back to Cielo Home App. • Select your home Wi-Fi Network from the list. • Enter the password of your home Wi-Fi Network. ENTER WI-FI NETWORK PASSWORD WI-FI LIST...
- Page 7 STEP 3A: REGISTER CONTROLLER – FOR iOS USERS (CONTINUED) • In the next screen, type device name of your choice. (For example, Master Bedroom, Lounge, etc.) • Next, select “manufacturer” and “remote model number” from respective drop down list. • In the next screen, “Allow Location Access” for enhanced functionality. Your registration process is complete. The Perfect Aire Smart Controller will appear on your home screen.
- Page 8 STEP 3B: REGISTER CONTROLLER – FOR ANDROID USERS • The Controller registration process is meant to connect the Perfect Aire Smart Controller by Cielo to your home Wi-Fi network through the Cielo Home App. • To begin registration: • Tap on “+” in the Home Screen • In the “Begin Registration” screen, press the Air Conditioner or Heat Pump icon. The App will automatically detect the Wi-Fi network your phone is connected to and will prompt for the password.
- Page 9 STEP 3B: REGISTER CONTROLLER – FOR ANDROID USERS (CONT.) • In case you do not want to connect the Controller to the displayed Wi-Fi network, press the Wi-Fi name link and a list of available Wi-Fi networks will be displayed. Select the desired Wi-Fi network and enter password. The Controller will connect to your selected Wi-Fi. ENTER WI-FI WI-FI LIST NETWORK PASSWORD...
- Page 10 QUICK TIP: FINDING THE RIGHT MODEL OF AC/HEAT PUMP 1. On your home screen in “Cielo Home” App, go to device settings by tapping “wrench symbol” on the registered device (for both Android & iOS users). 2. In the device settings, to go “Change Appliance” and change the remote model. 3. Repeat the process if your Air Conditioner/Heat Pump still does not work with the Controller. 4. If your specified remote model is not available in the list, you can visit remotes. cielowigle.com. The remote model is usually found on the back of the remote control. See example to the right for remote model...
- Page 11 STEP 4A: YOUR HOME SCREEN Your home screen shows the real-time status of all your connected Perfect Aire smart devices. If you have only one Perfect Aire Smart Controller, a single device will be displayed. A connected Controller displays 3 types of status, shown as outlined circles. GREEN – Device in online. RED – Device is offline. GREY WITH A WARNING SIGN – Device is already registered with another user. (NOTE: In cases where the Controller is not appearing online, please refer to the Troubleshooting section at the back of this manual.)
- Page 12 MODES 1. Configuration instructions can be found at https://cielosupport.zendesk.com TEMP. 2. Select “Breez – Wi-Fi Controller (Thermostat) for Air Conditioners & CONTROL Heat Pumps” 3. Select from the appropriate option from the three listed below and follow the step by step instructions: Configuring the Google Assistant with Breez POWER Configuring Amazon Alexa with Breez – Custom Skill “Cielo Home” SWING FAN SPEED OPERATION Configuring Amazon Alexa with Breez – Smart Skill “Cielo Smart Home” FOR SUPPORT, please contact us at 1.425.529.5775 or visit our website: CONTROL TIMELINE cielosupport.zendesk.com (select Breez) eSAVER...
- Page 13 TROUBLESHOOTING: CHANGING WI-FI NETWORK To change the Wi-Fi network of your Controller, tap wrench symbol on the registered device (for Android) or long- tapping (for iOS) to view the device settings screen. There are two ways to change the Wi-Fi network of your Controller. You can follow one of them. 1. If your device is perfectly connected to a Wi-Fi router and you want to configure it with another one, there are two ways to achieve this: OPTION 1: Make sure you are on same Wi-Fi network as the Controller. Press change Wi-Fi settings and it will automatically show you the list of Wi-Fi networks around the device. OPTION 2: If you are unable to follow Option 1 or the Wi-Fi network list is not showing by following these steps: • Turn off the Wi-Fi router to which the Controller is previously configured. Controller will start broadcasting and you can change the Wi-Fi network by connecting your mobile device to Controller. • Next, go to your phone settings > Wi-Fi to connect to the Wi-Fi that starts with “Cielo..”. A wizard will walk you through the necessary steps in order to connect your phone to the network. • After connecting to Controller Wi-Fi from your phone settings, go back to Cielo Home App. Available Wi-Fi network list will be displayed where you can select your home Wi-Fi. Enter the password and Controller will connect to your specified Wi-Fi network. 2. If the Wi-Fi network to which Controller was previously configured is unavailable or its password has been changed; Controller will automatically disconnect from the network and start broadcasting. Follow the Instructions mentioned in step 1(b) to change the Wi-Fi network.
- Page 14 TROUBLESHOOTING: CONTROLLER IS NOT SHOWING ONLINE 1. There might be the case when your entered password for the home Wi-Fi router is incorrect or Controller is unable to connect to the desired Wi-Fi network. Go to Mobile Settings > Wi-Fi Settings and see if the Controller is still showing in the Wi-Fi List. If this is the case, follow “Change Wi-Fi” troubleshooting guide to configure Wi-Fi network of Controller. This time, make sure you enter correct Wi-Fi network password and there is no restriction configured on your Wi-Fi network. 2. Check to see if there is a stable working internet available on your Wi-Fi network. Stable working internet connection is the primary requirement for Controller to work properly.
- Page 15 1. Perfect Aire, LLC is not liable for warranty. 2. Cielo WiGle Inc. warrants to the owner of the enclosed product that the product contained in this box (“Product”) will be free from defects in materials and workmanship for a period of one (1) years from the date of delivery following the original retail purchase (the “Warranty Period”).
-
Page 16: Technical Specifications
CONNECTED TO YOUR PRODUCTS (“PRODUCT PERIPHERALS”). THE TYPE OF PRODUCT PERIPHERALS THAT MAY BE CONNECTED TO YOUR PRODUCT MAY CHANGE FROM TIME TO TIME WITHOUT LIMITING THE GENERALITY OF THE DISCLAIMERS ABOVE. ALL PRODUCT INFORMATION IS PROVIDED FOR YOUR CONVENIENCE, “AS IS”, AND “AS AVAILABLE”. CIELO WIGLE INC.
