Kit Core Upgrade-EMB-B75B Without Modem
These instructions outline the procedures to install the EMB-B75B motherboard
into your existing Computer Core Chassis. There may be unused parts in this kit
depending on the style of Core being upgraded.
Tools Required
1/4" and 11/32" nut driver, #2 Philips Screw driver
Parts Included with this Kit:
Item #
Part Number
1
40924214
2
22219001
3
40980801
4
40980802
5
22144401
6
34072201
7
34052405
8
22132276
9
34037946
10
22132277
11
EC0358-01
12
EC0359-01
13
21889250
14
80402304
15
80351604
16
28277901
17
70800106
18
22190901
NOTE: If you are installing this kit into a Blue View Core Computer assembly, you will need to
order one additional harness. Order part number 22132280.

Installation Instructions

Kit #22166905
Description
Computer Board Assy EMB-B75B
SATA Hard Drive U.S.
Bracket Hard Drive Tray Replacement
Bracket SATA Mounting Adapter
Cover Computer Card (Not Shown)
Cover PSI Low Profile (Not Shown)
Power On/Reset CBA
Cable Assembly ON/Reset
Harness Assembly ATX Power
Cable Assembly DB9
Cable SATA Data
Harness SATA Power
DB9 Hardware (Not Shown)
#6-32 x ¼" Phillips (Not Shown)
#4-40 x ¼" Phillips (Not Shown)
M3 x 6 Phillips (Not Shown)
Tie Wrap (Not Shown)
Bracket Mounting (Hard Drive)
These Instructions
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
1
4
4
4
2
1
Page 1 of 12
22166955
REV. C

Advertisement

loading
Need help?

Need help?

Do you have a question about the EMB-B75B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for AMI EMB-B75B

  • Page 1: Installation Instructions

    Installation Instructions Kit Core Upgrade-EMB-B75B Without Modem Kit #22166905 These instructions outline the procedures to install the EMB-B75B motherboard into your existing Computer Core Chassis. There may be unused parts in this kit depending on the style of Core being upgraded.
  • Page 2 Figure 1 Page 2 of 12 22166955 REV. C...
  • Page 3 Caution: When installing this EMB-B75B motherboard, care should be taken to avoid static discharges that can damage the motherboard. The motherboard installation should be done on a static dissipative mat along with a grounding wrist strap. Removing the Motherboard and ON/OFF reset board 1.
  • Page 4 Installing the EMB-B75B Motherboard and 34052405 ON/OFF reset board 7. Insert the front panel into position and carefully align the new motherboard (Item #1) with the four existing studs on the computer core chassis. Secure the motherboard with four of the seven screws removed in step #6.
  • Page 5 Assembling the SATA Hard Drive with the Adapter Mounting Bracket 10. Secure the SATA hard drive 22219001 (Item #2) to the SATA Mounting Adapter Bracket 40980802 (Item #4) using the four M3 x 6 metric screws 28277901 (Item #16) as shown in Figure 4.
  • Page 6 12. Mount the replacement Hard Drive Tray Bracket 40980801 (Item #3) on the inside cover of your computer core using the four screws previously removed. Ensure the bracket properly covers the front opening. Thread the four 6-32 x ¼” screws 80402304 (Item #14) into the mounting adapter leaving approximately 1/16-inch gap.
  • Page 7 Connecting the SATA Hard Drive to the 611765XX Series Computer Core. 14. Disconnect the power and IDE Cables from the hard drive. Loosen the thumbscrew and remove the hard drive from the housing; it will not be reused. Insert the hard drive adapter bracket and hard drive assembled in step #10 into the housing and secure with the four fasteners.
  • Page 8 Connecting the SATA Hard Drive to the 61171001 Computer Core 15. Disconnect the power and IDE Cables from the hard drive. Loosen the four screws and remove the hard drive and bracket, it will not be reused. Attach the hard drive adapter bracket and hard drive (assembled in step #10) to the new Hard Drive Mounting Bracket 22190901 (Item #18) by aligning it with the slots and securing it with four screws 80402304 (Item #14).
  • Page 9 Connecting the SATA Hard Drive to the 61171002 Computer Core 16. Disconnect the power and IDE Cables from the hard drive. Remove the two thumbscrews and the two hard drive brackets from the hard drive (the hard drive will not be reused). Attach these two brackets to the hard drive adapter bracket and hard drive assembled in step #10 and secure with the same four screws.
  • Page 10 Connecting the SATA Hard Drive to the 70260-1A Series Rock-Ola Computer Core 17. Disconnect the power and IDE Cables from the hard drive. Remove the four thumbscrews from the hard drive (the hard drive will not be reused). Install the four thumbscrews into the adapter bracket and hard drive assembled in step #10.
  • Page 11 Connecting the SATA Hard Drive to the Modified View Computer Core 18. Disconnect the power and IDE Cables from the hard drive. Remove the four screws that mount the hard drive (the hard drive will not be reused). Install the adapter bracket and hard drive assembled in step #10.
  • Page 12 Page 12 of 12 22166955 REV. C...
