Table of Contents General Information .................... 15 Delivery Scope ....................16 General Safety Regulations ................16 Installing the Control Device ................16 Wall Mount ....................16 Electric Supply ....................18 Operation ......................19 Button Functions ..................19 Commissioning the Device ............... 20 Activating the Device for the First Time .............
General Information Dear Customer, with this coloured light control device, you have purchased a high-quality electronic device, which was designed and produced according to the latest standard and quality guidelines. With this high-quality coloured light controller, you "operate" your coloured light device and with the programming options, you will surely quickly find the settings you feel most comfortable with.
Delivery Scope (changes reserved) The control device consists of: l Plastic bag with three attachment screws 4 x 20 mm and three distancer tubes as well as 3 rubber sleeves. General Safety Regulations l Only an authorized electrician may install the electronics. l The regulations of your power supply company as well as the pertinent regulations of the Electrician's...
Page 5
Attachment holes Notice: If the sauna cabin is not Top attachment hole equipped with empty tubes, the sauna leads must be installed on the outside of the cabin, preferably in a groove of the profile boards. Therefore, the control device must be installed with a slight gab to enable you to guide the cables to the control device.
Electric Connection Only an approved electrician may install the electric equipment under observance of the guidelines of the local power supply company and the Electrician's Association. As a rule, there may only be one perma- nent mains connection. This must enable you to separate all poles of the device from the mains with a contact opening width of at least 3 mm.
Operation Button Functions LED for colour runtime LEDs for colours LED for operational readiness Mode On/Off Setting Single colour Mode buttons operating switch Program Ill. 6 automatic button operation english...
Commissioning the Device After you have once again checked all connections, commission the device by activating the fuses and/or the main switch. The device signals its readiness for operation with the green LED on the icon. MODE Activating the Device for the First Time By pressing the start/stop button for the first time after activating the supply...
Automatic Coloured Light Selection The automatic coloured light selection is activated by pressing the light button. With automatic coloured light selection, the colour sequence is red-red/yellow- yellow-yellow/green-green-green/blue- blue-blue/red. In the basic setting, the individual colours remain for 5 minutes and the mixed colours for 10 seconds (see "Preset Parameters").
Effects of the Colours The mental effect of the colours takes Blue, the colour of the sky and the water, place via the eyes. From there, the colour is associated with longing, vastness and radiation is transferred to the brain by cold.
Connection Diagram Electronic circuitry Line power feed 3 x 1.5 mm² Colored light unit 230 V/50 Hz Observe coding of feed lines to colored light unit Illust. 7 Technical Data Mains voltage: 230 V AC 50 Hz Fuse: 1 x 10 A Output per lamp: max.
