Titan Controls APOLLO 1 Instruction Manual page 2

Apollo 1
• Warnings
• Apollo 1- Repeat Cycle Timer with Photocell Overview
• Instructions for Operation
• Troubleshooting Tips
• Controller Specifications
• Installation Examples
• Warranty Information
• Service and Repair Program
Warnings
• Read all instructions before operating controller.
• Do not put your controller in an area where it can get wet or sprayed.
• Mount your controller securely to the wall using hardware provided.
• When using "bug bombs" in area, cover controller completely to avoid corrosion.
• There are no serviceable parts in controller. Do not attempt to repair the unit.
• Breaking "warranty" seal will void your warranty.
• Do not put paperclips, tools, etc. into unit. Possible electrocution may occur.
• Plug controller into surge protector to avoid potential damage to the unit.
• Make sure to verify your power source prior to plugging controller into outlet.
• Check that all equipment that will be activated by this controller is the proper voltage.
• This controller is designed for inside use only.
• Avoid placing the controller near heat generating sources.
• Use caution when operating controller in extremely humid environments.
• Do not use controller for purposes other than the unit was designed to function.
• Use controller within defined environmental specifications.
• Ask your Dealer for tips and techniques regarding the use of this controller.
• Be conscientious when disposing of any products.
• Enjoy your Titan Controls environmental controller for years to come!
Apollo 1 – Repeat Cycle Timer
with Photocell Overview
The Apollo 1- Repeat Cycle Timer with Photocell has two adjustment knobs and a switch that
may be used to configure the controller to perform as required.
The dial knob on the left side of the controller is used to adjust the "On time" of the load output.
The adjustment of the "On time" ranges from three (3) seconds to thirty (30) minutes. The dial
knob on the right side of the controller is used to adjust the "Off time" of the load output. The
WARRANTY SERVICE: Please read warranty information first
If after reviewing the troubleshooting tips the unit will still not work, you should return it to the
Dealer where you purchased it. They will be able to further evaluate the unit and test its various
components and quite possibly will be able to identify and/or fix any problems. If the Dealer is
unable to fix the unit, they will return it to us for factory repair.
If there are no Dealers in your area, you may contact us directly for technical support. If we cannot
help you resolve the problem over the phone, we will issue you a RMA # (return merchandise
authorization) authorizing you to return the unit to us for factory reconditioning (if the unit is under
warranty). Contact the number below for a RMA and shipping address. Complete the form below
and include it with your unit. Also please write the RMA # on the outside of the box.
Please package the unit in its original packaging. If it is damaged in shipment we cannot be
responsible.
Once we receive the unit back, we will repair it within 48 hours (business) and return it to you
freight prepaid via FedEx or UPS ground shipment.
Include the following if returning directly to Titan Controls
• Proof of purchase • This completed form • RMA # on the outside of the box
Return Merchandise Authorization Number (Required
Company Name: ____________________________________________________________________________________
Contact Name: _____________________________________________________________________________________
Address: __________________________________________________________________________________________
____________________________________________________________________________________________________
Phone #: ___________________________________________________________________________________________
Email address: _______________________________________________________________________________
______________________________________
What is the nature of the problem?
___________________________________________________________
___________________________________________________________
___________________________________________________________
___________________________________________________________
_______________________________________________________
Send to your nearest location – shipping address will be given when the RMA # is issued:
www.titancontrols.net
®
For technical assistance call us at 1-888-80-Titan or 1-888-808-4826.
