PCI-GPIB

Performance
GPIB
3-wire
HS488
Power Requirements
PCI-GPIB/TNT4882C
+3.3 V
+5 V
PCI-GPIB/TNT5004
+5 V
VIO
PCI-GPIB/LP (Low Profile)
+5 V
Physical Characteristics
Dimensions
PCI-GPIB/TNT4882C
PCI-GPIB/TNT5004
PCI-GPIB/LP
1
PCI-GPIB boards manufactured before 2003 use the TNT4882C controller. The assembly number printed
on these boards is 183617x-01.
2
A later revision of PCI-GPIB boards uses the TNT5004 controller. The assembly number printed on these
boards is 188513x-01.
3 PCI-GPIB/LP is a low profile PCI-GPIB board designed to fit in low-profile machines. It uses a special
cable to convert between the micro-DSub connector of the board and the GPIB connector.
26 | ni.com | GPIB Hardware Installation Guide and Specifications
1
2
3
up to 1536 kbytes/s
up to 7885 kbytes/s
121 mA, Typical
182 mA, Maximum
300 mA, Typical
450 mA, Maximum
150 mA, Maximum
5 mA, Maximum
300 mA, Typical
450 mA, Maximum
13.3 cm × 10.7 cm (5.25 in. × 4.20 in.)
12 cm × 6.44 cm (4.72 in. × 2.54 in.)
12 cm × 6.44 cm (4.87 in. × 2.54 in.)
