- Page 1 GPIB-USB Interfaces Getting Started 2024-12-10...
- Page 2 GPIB Pinout ..............6 ni.com...
-
Page 3: Overview
GPIB cable required for instrument connection, you can use the Hi‑Speed USB port to control up to 14 programmable GPIB instruments. The device includes a license for the NI‑488.2 driver software, providing maximum reliability for connecting to third-party instruments with GPIB. - Page 4 GPIB interface. Otherwise, the GPIB interface is detected when you start your computer. Figure 1. Installing the GPIB-USB Interface 1 Computer 2 USB Connector 3 GPIB-USB Interface 4 To GPIB Devices The GPIB hardware installation is now complete. ni.com...
-
Page 5: Led Signaling
If the LED does not light, try reinstalling the NI-488.2 driver. Indicates that the GPIB-USB-HS+ is plugged into a USB full-speed (USB 1.1) Steady Green port. Indicates that the GPIB-USB-HS+ is plugged into a USB Hi-Speed ( USB 2.0) Steady Amber port. Blinking Amber or Indicates activity on the GPIB bus or that the GPIB Analyzer is capturing. -
Page 6: Gpib Pinout
DIO2 Data Input/Output Bit. DIO3 Data Input/Output Bit. DIO4 Data Input/Output Bit. End-Or-Identify. Data Valid. NRFD Not Ready For Data. NDAC Not Data Accepted. Interface Clear. Service Request. Attention. SHIELD Shield. DIO5 Data Input/Output Bit. DIO6 Data Input/Output Bit. ni.com... -
Page 7: Signal Ground
GPIB-USB Interfaces Getting Started Signal Terminal Description DIO7 Data Input/Output Bit. DIO8 Data Input/Output Bit. Remote Enable. Ground—Wire twisted with DAV. Ground—Wire twisted with NRFD. Ground—Wire twisted with NDAC. Ground—Wire twisted with IFC. Ground—Wire twisted with SRQ. Ground—Wire twisted with ATN. SIGNAL GROUND Logic Ground.
