RAID 5

Deleting a RAID

To delete a RAID volume, follow the steps below:
1. On the RAID List screen, select the RAID volume by clicking on its radio
button, and click RAID Config to open the RAID Configuration screen.
2. On the RAID Configuration screen, click Remove RAID.
3. The confirmation screen appear, you will have to input "Yes" with exactly
wording case to complete "Remove RAID" operation
WARNING

Space Allocation

You may specify the space allocated for both Target USB and iSCSI volumes.
To do this, under the Storage menu, click RAID and the RAID List window
appears. Select the RAID volume you wish to reallocate by clicking on its radio
button, and click Space Allocation. The RAID Information and Volume
Allocation List windows will appear.
The Volume Allocation List displays the space allocated for iSCSI volumes on the
current RAID volume. The N7700 supports up to 5 iSCSI volumes in each RAID
volume.
Volume Allocation List
Item
Modify
Del
Type
Name
Capacity
iSCSI Target

Allocating Space for iSCSI Volume

To allocate space for an iSCSI volume on the current RAID volume, follow the
steps below:
1. Under the Volume Allocation List, click iSCSI Target.
X
Removing RAID destroys all data in the current RAID volume. The data
is unrecoverable.
Description
Click this to modify the allocated space.
Click this to delete the allocated space.
Type of volume. Can be either USB or iSCSI.
Name assigned to the volume.
Capacity of the allocated space.
Click to allocate space to iSCSI volume.
33
[RAID 5] HDDx3 to [RAID 5] HDDx4
[RAID 5] HDDx3 to [RAID 5] HDDx5
[RAID 5] HDDx4 to [RAID 5] HDDx5
